User manual Softron OnTheAir Switch 3.IB29

Operating instructions and pdf manual for use - Softron OnTheAir Switch 3.IB29 User manual, User manual Softron OnTheAir Switch 3.IB29, Softron, OnTheAir, Switch, 3.IB29, Video


User manual for Softron OnTheAir Switch 3.IB29

Softron  OnTheAir Switch 3.IB29
  • Manufacturer: Softron
  • Basic description and contents of package
  • Product classification: Professional Video - Studio & EFP Equipment - Streaming Media Software
  • Safety instructions
  • Startup and operation of the streaming media software
  • Tips for setting up your Softron
  • Settings and expert assistance
  • Contact Softron service
  • Troubleshooting
  • Warranty information
  • Price: 945 USD
We recommend checking out our discussion threads on the Softron OnTheAir Switch 3.IB29, which address similar problems with connecting and setting up Streaming Media Software Softron.



User manual for the Softron OnTheAir Switch 3.IB29

The user manual for the Softron OnTheAir Switch 3.IB29 provides necessary instructions for the proper use of the product Professional Video - Studio & EFP Equipment - Streaming Media Software.

The OnTheAir Switch software from Softron is an application capable of controlling multiple matrix video switchers via RS232 or Ethernet. It supports most video routers, including AJA KUMO, Blackmagic Design Videohub, Evertz, Knox, Kramer / Kramer 2000, Leitch, Panacea (Leitch), Sigma MRX, Sony BRS-200, and Triton. The software is AppleScriptable, enabling it to be managed from any application-- even those from third parties. It may be utilized as a standalone application or integrated with most Softron products, including OnTheAir Video, MovieRecorder or OnTheAir Node. The software is compatible with the Mac OS, and may be used with any MacPro, iMac, MacBook Pro, MacBook Air or Mac mini.
If you own a Softron streaming media software and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Softron OnTheAir Switch 3.IB29 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Softron OnTheAir Switch 3.IB29:
Specifications
    Minimum System Requirements Mac OS X 10.5.8 or later
    2.0 GB RAM
    Additional Hardware required: USB to RS232 or RS422 converter - only for video routers controlled in RS232 or RS422; not required for AJA KUMO and Blackmagic Videohub
    If router controlled via Ethernet (AJA KUMO and Blackmagic Design Videohub), you will only need Mac to be connected to same Network as router you wish to control - will show up in Bonjour
    RS422 port of video cards not configurable
    RS232 port of Xserves not configurable
    MacPro, iMac, MacBook Pro, MacBook Air, or Mac mini (any)
    Supported Video Routers AJA KUMO:
    Protocol: Ethernet
    Model: All
    Baud Rate, Parity, Bits, Stop Bit not applicable

    Blackmagic Design Videohub:
    Protocol: Ethernet
    Model: All
    Baud Rate, Parity, Bits, Stop Bit not applicable

    Evertz:
    Protocol: RS232
    Model: 32 x 32
    Baud Rate: 38.400 baud
    Parity: No parity
    Bits: 8 bits
    Stop Bit: 1

    Knox:
    Protocol: RS232
    Model: 8 x 8
    Baud Rate: 19.200 baud
    Parity: No parity
    Bits: 8 bits
    Stop Bit: 1

    Kramer 2000:
    Protocol: RS232
    Model: 8 x 2, 8 x 8
    Baud Rate: 9.600 baud
    Parity: No parity
    Bits: 8 bits
    Stop Bit: 1

    Kramer:
    Protocol: RS232
    Model: 8 x 2
    Baud Rate: 1.200 baud
    Parity: No parity
    Bits: 8 bits
    Stop Bit: 1

    Leitch:
    Protocol: RS232
    Model: 32 x 32
    Baud Rate: 38.400 baud
    Parity: Even parity
    Bits: 8 bits
    Stop Bit: 1

    Panacea (Leitch):
    Protocol: RS232
    Model: 8 x 2, 16 x 8, 32 x 32
    Baud Rate: 19.200 baud
    Parity: No parity
    Bits: 8 bits
    Stop Bit: 1

    Sigma MRX:
    Protocol: RS232
    Model: 32 x 32
    Baud Rate: 38.400 baud
    Parity: No parity
    Bits: 8 bits
    Stop Bit: 1
    Other settings: x on - x off flow control

    Sony BRS-200:
    RS422
    Model: 12 x 2
    Baud Rate: 38.400 baud
    Parity: Odd parity
    Bits: 8 bits
    Stop Bit: 1

    Triton:
    Protocol: RS232
    Model: 8 x 8, 64 x 64
    Baud Rate: 19.200 baud
    Parity: No parity
    Bits: 8 bits
    Stop Bit: 1
    The user manual for the Softron OnTheAir Switch 3.IB29 can be downloaded in .pdf format if it did not come with your new streaming media software, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Softron users keep a unique electronic library for Softron streaming media softwares, where you can use our link to download the user manual for the Softron OnTheAir Switch 3.IB29.

    The user manual lists all of the functions of the Softron OnTheAir Switch 3.IB29, all the basic and advanced features and tells you how to use the streaming media software. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Softron service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Softron OnTheAir Switch 3.IB29. User manuals are also available on the Softron website under Professional Video - Studio & EFP Equipment - Streaming Media Software.
