The Matrix2 from Solid State Logic is combination console/controller designed for use in a hybrid production studio, and is an effective solution for those who wish to incorporate the sonic advantages of SSL summing and a collection of boutique analog microphone preamps and processors into a DAW-centric studio. The console/controller is fully capable of integrating monitors, workstations, and outboard gear for a smooth workflow.

The analog side of unit combines a forty input SuperAnalogue summing mixer, along with fully featured monitor switching and talkback, and a built-in "Insert Router" which allows for single or chains of analog outboard processors to be inserted quickly and easily. With a single button push, the 16 + 1 fader hardware control surface switches from controlling the analog signal path to functioning as a comprehensive multi-layer DAW control surface.
If you own a Solid State Logic analog recording mixers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Solid State Logic Matrix2 - SuperAnalogue Summing 729940X2 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Solid State Logic Matrix2 - SuperAnalogue Summing 729940X2:
Specifications
    Electrical Characteristics Performance
    Headroom: <+26 dBu @ 1 kHz (<1% THD)

    Line In to Direct Out
    Frequency Response: +/-0 dB at 20Hz, +0/-0.1 dB at 20 kHz, -1 dB at 80 kHz
    Noise: <-89 dBu (20 Hz to 22 kHz)
    THD: <0.002% @ 1 kHz (+24 dBu, 22 kHz filter)

    Line to Aux Bus Out
    Frequency Response: +/-0 dB at 20 Hz, +0/-0.1 dB at 20 kHz
    Noise: <-93 dBu (no channels routed), <-76dBu (all channels routed, faders at 0dB)
    THD: <0.002% @ 1 kHz (+24 dBu, 22 kHz filter)

    Line to Mix/Rec Bus Out
    Frequency Response: +/-0 dB at 20 Hz, +0/-0.1 dB at 20 kHz
    Noise: <-89 dBu (no channels routed), <-77.5 dBu (all channels routed, faders at 0 dB, pan at center)
    THD: <0.002% @ 1 kHz (+24 dBu, 22 kHz filter)
    Digital I/O Test conditions (unless otherwise specified): Input test signal is a 1 kHz sine wave; measurement bandwidth is 22 Hz to 22 kHz, signal level is -1 dB FS)
    Stereo ADC
    Source selectable between Mix bus, Record bus and Monitor (pre level control) signals
    Connections: S/PDIF (TOSLink optical) and AES-3 (male XLR) - signal available on both connectors at all times
    Sample Rate: Locks to selected digital input up to a maximum sample rate of 192 kHz (in the absence of a valid digital input defaults to 48 kHz)
    Dynamic Range: Typically 113 dB A-weighted, 111 dB unweighted, 108 dB unweighted worst case
    THD: <0.0015%
    0 dB FS: Switchable between +18 dBu and +24 dBu

    DAC
    Connections: Source selectable from Matrix front panel between S/PDIF (TOSLink optical) and AES-3 (female XLR) inputs
    Sample Rate: 32 kHz to 192 kHz
    Dynamic Range: Typically 116 dB A-weighted, 111 dB unweighted, 109 dB unweighted worst case
    THD: < 0.001%
    0 dB FS: Switchable between +18 dBu and +24 dBu
    Other Heat Dissipation
    Console: 130 W (approximately)
    Power Supply: 45 W (approximately)

    Noise
    Console: None, fanless
    Power Supply: None, fanless
    Power Requirements 100~240 VAC, 50/60 Hz (+/-10%)
    Dimensions (WxDxH) Console: 37.2 x 28.5 x 9" (946 x 724 x 228 mm)
    Power Supply: 4.2 x 12.1 x 8" (106 x 306 x 202 mm)
    Weight Console: 55.1 lb (25 kg)
    Power Supply: 11 lb (5 kg)
