User manual for the Sony UTX-B03 Integrated Digital Wireless Bodypack UTXB03/14
The user manual for the Sony UTX-B03 Integrated Digital Wireless Bodypack UTXB03/14 provides
necessary instructions for the proper use of the product Pro Audio - Location Sound - Wireless Transmitters.
The 470 to 542 MHz version of the Sony UTX-B03 Integrated Digital Wireless Bodypack Transmitter with Lavalier Microphone features an all-metal chassis, an easy to read LCD display, a wide switching RF bandwidth, USB power and charging options, infrared synchronization between transmitter and receiver, a Mic/Line switchable input, and digital companding circuitry to improve the transient response of received audio. The package is suitable for a wide range of wireless applications such as ENG (electronic news gathering), documentary work, talk shows, conferences, and more.
If you own a Sony wireless transmitters and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Sony UTX-B03 Integrated Digital Wireless Bodypack UTXB03/14 in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Sony UTX-B03 Integrated Digital Wireless Bodypack UTXB03/14:
| Frequency Response || 40 to 20,000 Hz |
| Directivity || Omnidirectional |
| Capsule || Condenser |
| Sensitivity || -43.0 dB ±3.0 dB (1 kHz/Pa) |
| Dynamic Range || 86 dB or more |
| Maximum Input || 120 dB SPL |
| Microphone Head Size || 0.27 x 0.77" (6.8 x 19.5 mm) |
| Power Requirements || 5 VDC |
| Cable Length || 3.9' (1.2 m) |
| Weight || Not specified by the manufacturer |
| Type of Transmitter || Crystal-controlled UHF PLL-synthesized bodypack transmitter |
| Antenna || 1/4 wave length wire |
| Emission || F3E |
| Carrier Frequency Range || 470 to 542 MHz |
| RF Bandwidth || 72 MHz |
| RF Power || 30 mW / 5 mW |
| Type of Input Connector || Mic/Line Switchable - 3-pole locking mini microphone connector (3.5 mm) |
| Interchangeable Mic Heads || Compatible with any microphone that features a mini (3.5mm) connection |
| Reference Input Level || Mic: -60 dBV (at 0-dB attenuator level) |
Line: +4 dBu
| Attenuation / Gain || Mic: 0 to 21 dB (in 3 dB steps) |
| Frequency Response || 23 to 18,000 Hz (typical) |
| Signal to Noise Ratio || 96 dB (max deviation, A-weighted) |
| Audio Delay || Approximately 0.35 msec |
| Pilot Tone || 32 kHz / 32.382 kHz / 32.768 kHz |
| Display || LCD |
| Power Requirements || 3.0 VDC (with two AA-size alkaline LR6 batteries) |
5.0 VDC (via USB micro-B)
| Battery Type/Approx. Life || Approximately 8 hours with Sony's AA-size alkaline (LR6) batteries at 77°F (25°C) at 30 mW output |
| Operating Temperature || 32 to 122°F (0 to 50°C) |
| Storage Temperature || -4 to 131°F (-20 to 55°C) |
| Dimensions (W x H x D) || 2.48 x 3.23 x 0.79" (63 x 82 x 20 mm) |
| Weight || 5.26 oz (149 g) with batteries |
| Package Weight || 0.9 lb |
| Box Dimensions (LxWxH) || 9.8 x 5.9 x 3.8" |
