User manual for the Thermaltake Smart Series Standard 650W Power Supply Unit SP-650P
The user manual for the Thermaltake Smart Series Standard 650W Power Supply Unit SP-650P provides
necessary instructions for the proper use of the product Computers & Solutions - Computer Components - Power Supplies.
The black Smart Series Standard 650W Power Supply Unit from Thermaltake is ideal for you to build a stable home or office system for 24/7 use. It is 80 Plus Bronze certified and offers up to 88% energy efficiency at 20 to 100% load under real world load conditions. The unit features flat and low-profile cables that increase the airflow. It is equipped with a pure single +12V rail to provide better compatibility for your PC. The quiet smart temperature controlled fan can automatically detect power load and adjusts fan speed.
|
If you own a Thermaltake power supplies and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Thermaltake Smart Series Standard 650W Power Supply Unit SP-650P in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Thermaltake Smart Series Standard 650W Power Supply Unit SP-650P:
| Type | Intel ATX 12V Version 2.3 | | MTBF | Minimum: 100,000 hours | | Output Capacity Details | Maximum: 650 W | | Peak Output Capacity | 780 W | | Output Current | Maximum: +3.3 V: 24 A
+5 V: 24 A
+12 V: 52 A
-12 V: 0.5 A
+5 VSB: 3.0 A | | Output Power | Maximum: +3.3 V and +5 V: 120 W
+12 V: 624 W
-12 V: 6.0 W
+5 VSB: 15 W | | Input Current | 10 A | | Input Frequency Range | 47 to 63 Hz | | Input Voltage | 100 to 240 VAC | | Connectors | 1 x 24-pin
1 x 4+4-pin CPU
2 x PCIe (6+2-pin)
6 x SATA
4 x peripheral (4-pin)
1 x floppy (4-pin) | | Power Factor Correction | Active PFC | | Power Good Signal | 100 to 500 ms | | Hold Up Time | 16 ms (minimum) at 80% of full load at 115 VAC/230 VAC input | | Fan | 4.7" (120.0 mm), 1800 rpm ± 10% | | Efficiency | 82 to 88% efficiency at 20 to 100% load | | Power Factor Correction | Active PFC | | Input Voltage | 100 to 240 VAC | | Protection | OVP, UVP, OCP, OPP, and SCP | | Operating Temperature | 32 to 104°F (0 to 40℃) | | Storage Temperature | -4 to 158°F (-20 to 70℃) | | Operating Humidity | 20 to 90% (non-condensing) | | Storage Humidity | 5 to 95% (non-condensing) | | Safety Approvals | UL, CUL, TUV, CE, FCC, and BSMI | | Dimensions (W x H x D) | 5.9 x 3.3 x 5.5" (150.0 x 86.0 x 140.0 mm) | | Package Weight | 4.9 lb | | Box Dimensions (LxWxH) | 9.4 x 8.7 x 4.5" | |
