Designed for gaming and PC enthusiasts, multi-core processors, and multi-GPU configurations, the Toughpower Grand 850W Platinum Modular Power Supply from SilverStone features an 850W maximum output capacity, a 1020W peak output capacity, a single +12V rail, and an 80 Plus Platinum certification that delivers up to 89-92% efficiency. Its 140mm fan not only helps to provide cooling, but also operates with noise levels of up to 20 dB. Other built-in features include a fully modular cable design, flat modular cables, and Japanese capacitors.
This eco-friendly PSU also helps to reduce your power bills and is compatible with Intel ATX12V V2.3 & EPS12V. It operates using 100-240 VAC at 50-60 Hz and has a MTBF of 120,000 hours. The Toughpower Grand 850W Platinum Modular Power Supply is protected by a limited 7-year parts and labor warranty.
If you own a Thermaltake power supplies and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Thermaltake Toughpower Grand 850W 80 Plus PS-TPG-0850FPCPUS-P in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Thermaltake Toughpower Grand 850W 80 Plus PS-TPG-0850FPCPUS-P:
Specifications
Type
Intel ATX12V V2.3 & EPS12V standards
Max. Output Capacity
850 W
Peak Output Capacity
1,020 W
Color
Black
PFC (Power Factor Correction)
Active PFC
Power Good Signal
100-500 ms
Hold Up Time
16 ms (minimum) @ 75% of full load at 115 / 230 VAC input
Input Current
5.5~11 A
Input Frequency Range
50-60 Hz
Input Voltage
100-240 VAC
Number of +12V Rails
DC Output: +3.3 V Max Output Current: 25 A Max Output Power: 120 W Continuous Power: 850 W
DC Output: +5 V Max Output Current: 22 A Max Output Power: 120 W Continuous Power: 850 W
DC Output: +12 V Max Output Current: 70 A Max Output Power: 840 W Continuous Power: 850 W
DC Output: -12 V Max Output Current: 0.3 A Max Output Power: 3.6 W Continuous Power: 850 W
DC Output: +5 Vsb Max Output Current: 2.5 A Max Output Power: 12.5 W Continuous Power: 850 W
Operating Temperature
32 to 122°F / 0 to 50°C
Operating Humidity
10 to 90%, non-condensing
Storage Temperature
-4 to 140°F / -20 to 60°C
Storage Humidity
20% to 95%, non-condensing
Cooling System
140 mm fan
Efficiency
89-92% efficiency @ 20-100% load
MTBF
120,000 hours minimum
Safety Approvals
UL/TUV/CE/FCC/EAC certification
PCIe Connector
PCIe 6+2-pin x 6
Dimensions
3.4 x 5.9 x 7.1" / 86.0 x 150.0 x 180.0 mm
Weight
Not specified by manufacturer
