User manual for the Toyo-View 45AX Metal Field Camera 180-223
The user manual for the Toyo-View 45AX Metal Field Camera 180-223 provides
necessary instructions for the proper use of the product Photography - Film Cameras - Large Format Cameras.
The Toyo 45AX comes with a vertical/horizontal quick-change back, acid-etched grid groundglass with 6x7 and 6x9cm markings, fresnel, 1/4" and 3/8" interchangeable tripod sockets, #0 110mm square lensboard.
If you own a Toyo-View large format cameras and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Toyo-View 45AX Metal Field Camera 180-223 in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Toyo-View 45AX Metal Field Camera 180-223:
| Tilts || Front: 90° forward, 15 degrees backward |
Rear: 90° forward, 15° backward
| Swings || Front: 8° left, 8° rightRear: 8° left, 8° right |
| Rise & Fall || Front: 20mm rise, 23mm fall |
| Shifts || Front: 7mm left and right |
| Camera Back || 4x5 Vertical/Horizontal quick-change International Standard Graflok |
Groundglass w/ acid etched gridlines, 6x7 and 6x9 markings
| Interchangeable Bellows || No |
| Minimum Extension || 2.8" (70mm) with flat lensboard, 2.3" (58mm) with 12mm recessed lensboard |
| Maximum Extension || 12.8" (324mm) - Optional 4" Extension Back is available for long focal lenses |
| Lensboard || Toyo 110 x 110mm flat or recessed boards, or misc lensboard adapters |
| Dimensions || 7.4 x 8.3 x 4.2" (18.8 x 20.9 x 10.7 cm) |
| Weight || 6.2 lbs (2.8 kg) |
| Package Weight || 6.35 lb |
| Box Dimensions (LxWxH) || 10.1 x 9.1 x 5.6" |
