User manual for the Ubiquiti Networks LBE-5AC16120-US LiteBeam 5 GHz LBE-5AC16120-US
The user manual for the Ubiquiti Networks LBE-5AC16120-US LiteBeam 5 GHz LBE-5AC16120-US provides
necessary instructions for the proper use of the product Computers & Solutions - Networking - Wireless Bridges.
Snap together the LBE-5AC16120-US LiteBeam 5 GHz airMAX Technology Solution from Ubiquiti Networks and take advantage of a longer-range, higher-performance network antenna to reach users at greater distances. Operating on the license-free 5 GHz frequency, you can take advantage of data transfer rates of up to 100+ Mbps at distances of up to 18+ mi (30+ km). Combine the improved distance with Ubiquiti Networks' own airMAX technology and you benefit from increased airtime efficiency through the use of Time Division Multiple Access or TDMA technology. Additionally, airMAX technology offers intelligent QoS and improved scalability.
|
If you own a Ubiquiti Networks wireless bridges and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Ubiquiti Networks LBE-5AC16120-US LiteBeam 5 GHz LBE-5AC16120-US in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Ubiquiti Networks LBE-5AC16120-US LiteBeam 5 GHz LBE-5AC16120-US:
| Wind Survivability | 125 mph (200 km/h) | | Wind Loading | 17.3 lbf @ 125 mph (77 N @ 200 km/h) | | Mounting Kit | Pole mounting kit (included) | | Max Power Consumption | 7 W | | Power Supply | 24 V, 0.5 A Gigabit PoE adapter (included) | | Power Method | Passive PoE (pairs 4, 5+; 7, 8 return) | | Temperature & Humidity | Operating temperature: -40 to 158°F (-40 to 70°C)
Operating humidity: 5 to 95% non-condensing | | Shock and Vibration | ETSI300-019-1.4 | | ETSI Specification | EN 302 326 DN2 | | ESD/EMP Protection | ± 24 KV contact / air | | Processor | MIPS 74 K | | Memory | 64 MB | | Networking Interface | 1 x 10/100/1000 Ethernet port | | Wireless Approvals | FCC, IC, CE | | RoHS Compliance | Yes | | Output Power | Output Power: 25 dBm
Modulation: airMAX ac
TX Power Specifications
Data Rate Avg. TX Tolerance
1x BPSK (½) 25 dBm ± 2 dB
2x QPSK (½) 25 dBm ± 2 dB
2x QPSK (¾) 25 dBm ± 2 dB
4x 16QAM (½) 25 dBm ± 2 dB
4x 16QAM (¾) 25 dBm ± 2 dB
6x 64QAM (2/3) 25 dBm ± 2 dB
6x 64QAM (¾) 24 dBm ± 2 dB
6x 64QAM (5/6) 23 dBm ± 2 dB
8x 256QAM (¾) 21 dBm ± 2 dB
8x 256QAM (5/6) 21 dBm ± 2 dB
RX Power Specifications
Data Rate Sensitivity Tolerance
1x BPSK (½) -96 dBm ± 2 dB
2x QPSK (½) -95 dBm ± 2 dB
2x QPSK (¾) -92 dBm ± 2 dB
4x 16QAM (½) -90 dBm ± 2 dB
4x 16QAM (¾) -86 dBm ± 2 dB
6x 64QAM (2/3) -83 dBm ± 2 dB
6x 64QAM (¾) -77 dBm ± 2 dB
6x 64QAM (5/6) -74 dBm ± 2 dB
8x 256QAM (¾) -69 dBm ± 2 dB
8x 256QAM (5/6) -65 dBm ± 2 dB | | Operating Frequency | Worldwide: 5150 - 5875 MHz
USA: 5725 - 5850 MHz | | Gain | 16 dBi | | Max VSWR | 1.5:1 | | Dimensions | 17.81 x 3.10 x 2.14" (452.3 x 78.7 x 54.4 mm) | | Weight | 14.82 oz (420 g) | | Package Weight | 2.2 lb | | Box Dimensions (LxWxH) | 18.8 x 4.1 x 3.1" | |
The user manual for the Ubiquiti Networks LBE-5AC16120-US LiteBeam 5 GHz LBE-5AC16120-US can be downloaded in .pdf
format if it did not come with your new wireless bridges, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other Ubiquiti Networks users keep a unique electronic library
for Ubiquiti Networks wireless bridgess,
where you can use our link to download the user manual for the Ubiquiti Networks LBE-5AC16120-US LiteBeam 5 GHz LBE-5AC16120-US.
The user manual lists all of the functions of the Ubiquiti Networks LBE-5AC16120-US LiteBeam 5 GHz LBE-5AC16120-US,
all the basic and advanced features and tells you how to use the wireless bridges.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from Ubiquiti Networks service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the Ubiquiti Networks LBE-5AC16120-US LiteBeam 5 GHz LBE-5AC16120-US. User manuals are also
available on the Ubiquiti Networks website under Computers & Solutions - Networking - Wireless Bridges.
Question and answer discussion forum concerning user instructions and resolving problems with the Ubiquiti Networks LBE-5AC16120-US LiteBeam 5 GHz LBE-5AC16120-US - no comments have been made yet - be the first to add a comment
