User manual for the Used Nikon D5200 DSLR Camera (Body Only) 1501B
The user manual for the Used Nikon D5200 DSLR Camera (Body Only) 1501B provides
necessary instructions for the proper use of the product - Refurbished - SLR Digital Cameras.
The Nikon D5200 DSLR Camera features a 24.1MP DX-format CMOS sensor and EXPEED 3 image processor to produce high quality imagery while delivering fast performance to all camera functions. The combination of these two technologies is a native sensitivity up to ISO 6400, which is then further expandable to ISO 25600. The processing speed of the EXPEED 3 also contributes to a fast continuous shooting rate of 5fps.
A 39-point autofocus system enables the D5200 to acquire precise focus quickly across the image frame, and nine cross-type points are centrally located to give even more accurate focusing abilities to critical subject matter. In regard to exposure handling, a 2,016-pixel RGB sensor is utilized by Nikon's Scene Recognition System to analyze both color and brightness values within a scene to best determine exposure settings as well as white balance, i-TTL, and also focus settings.
HD video recording is supported in multiple frame rates and formats up to full HD 1920 x 1080 at 60fps. Manual exposure control is possible during recording through modifying the shutter speed or ISO settings and continuous auto focusing is also possible when working with the full-time servo AF mode. Audio can be recorded using the built-in stereo microphone or through the use of an optional external microphone, both of which can be manually controlled across 20 levels during recording.
Image playback and live view monitoring is possible with the 3.0" 921k-dot LCD monitor, which features tilt and swivel capabilities for better use at high or low angles. For eye-level viewing, a pentamirror optical viewfinder is built-in for viewing and composing scenes quickly and intuitively.
The D5200 features a variety of built in imaging technologies, such as Active D-Lighting and HDR capabilities, to further enhance the look of your imagery while shooting. Scene modes, Picture Control, and Special Effects can also be applied to imagery to give a more creative, aesthetic appearance to your work. For instantly sharing your photos and video, the D5200 is compatible with the WU-1a Wireless Mobile Adapter (optional) for wirelessly connecting your camera to an Android or iOS mobile device.
|
If you own a Nikon slr digital cameras and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Used Nikon D5200 DSLR Camera (Body Only) 1501B in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Used Nikon D5200 DSLR Camera (Body Only) 1501B:
| Lens Mount | Nikon F | | Camera Format | DX / (1.5x Crop Factor) | | Pixels | Actual: 24.71 Megapixel
Effective: 24.1 Megapixel | | Max Resolution | 6000 x 4000 | | Aspect Ratio | 3:2 | | Sensor Type / Size | CMOS, 23.5 x 15.6 mm | | File Formats | Still Images: JPEG, RAW
Movies: MOV, MPEG-4 AVC/H.264
Audio: Linear PCM | | Bit Depth | 14-bit | | Dust Reduction System | Yes | | Memory Card Type | SD
SDHC
SDXC | | Focus Type | Auto & Manual | | Focus Mode | Continuous-servo AF (C), Focus Lock AF Area Mode, Manual Focus (M), Single-servo AF (S) | | Autofocus Points | 39 | | Viewfinder Type | Pentamirror | | Viewfinder Coverage | 95% | | Viewfinder Magnification | Approx. 0.78x | | Diopter Adjustment | - 1.7 to +0.7 m | | Display Screen | 3" Rear Screen Swivel LCD (921,000) | | Screen Coverage | 100% | | Diagonal Angle of View | 170.0° | | ISO Sensitivity | Auto, 100-6400 (Extended Mode: 100-25600) | | Shutter | Type: Charge-coupled Electronic
Speed: 30 - 1/4000 second | | Remote Control | ML-L3 (Optional) | | Metering Method | 3D Color Matrix Metering, Center-weighted average metering, Spot metering | | Exposure Modes | Modes: Aperture Priority, Auto, Flash Off, Manual, Program, Shutter Priority
Compensation: -5 EV to +5 EV (in 1/3, 1/3 or 1/2 EV steps) | | White Balance Modes | Auto, Cloudy, Custom, Daylight, Flash, Fluorescent, Incandescent, Preset Manual, Shade | | Flash Modes | Auto
Auto/Red-eye Reduction
Fill-in
Off
Red-eye Reduction
Second-curtain Sync
Slow Sync
Slow Sync/Red-eye Reduction | | Built-in Flash | Yes | | Guide No. | 39' (11.89 m) ISO100 | | Max Sync Speed | Electronic Shutter: 1 / 200 seconds | | Flash Compensation | -3 EV to +1 EV (in 1/3 or 1/2 EV steps) | | Dedicated Flash System | iTTL | | External Flash Connection | Hot Shoe | | Video Recording | Yes, NTSC/PAL | | File Size | 1920 x 1080i (Full HD)
1920 x 1080p (Full HD)
1280 x 720p (HD)
640 x 424p (SD) | | Aspect Ratio | 16:9 | | Frame Rate | @ 1920 x 1080: 60 fps, 30 fps, 24 fps
@ 1920 x 1080: 50 fps, 25 fps
@ 1280 x 720: 60 fps, 50 fps
@ 640 x 424: 30 fps, 25 fps | | Exposure Control | Auto: Shutter Speed, Aperture, ISO
Manual: Shutter Speed, ISO | | ISO Sensitivity | Auto, 200 - 6400 | | Exposure Compensation | -0 EV to +2 EV (in 1/3, 2/3 or 1 EV steps) | | Focus | Auto
Manual
Continuous Auto | | Audio Recording | Optional External Mic: With Video, Stereo | | Continuous Shooting | Up to 5 fps | | Self Timer | 2 seconds, 5 seconds, 10 seconds, 20 seconds
Number of Shots: 1-9 | | Interval Recording | Yes | | Connectivity | 1/8" Microphone
HDMI C (Mini)
USB 2.0 | | Wi-Fi Capable | Yes | | Battery | 1x EN-EL14 Rechargeable Lithium-ion Battery Pack, 7.4 VDC, 1030 mAh | | Operating/Storage Temperature | Operating
32 to 104°F (0 to 40°C)
Humidity: 0 - 85% | | Dimensions (WxHxD) | 5.1 x 3.9 x 3.1" / 129.0 x 98.0 x 78.0 mm | | Weight | 1.22 lb / 555 g | | Package Weight | 3.05 lb | | Box Dimensions (LxWxH) | 8.5 x 7.7 x 6.1" | |
The user manual for the Used Nikon D5200 DSLR Camera (Body Only) 1501B can be downloaded in .pdf
format if it did not come with your new slr digital cameras, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other Nikon users keep a unique electronic library
for Nikon slr digital camerass,
where you can use our link to download the user manual for the Used Nikon D5200 DSLR Camera (Body Only) 1501B.
The user manual lists all of the functions of the Used Nikon D5200 DSLR Camera (Body Only) 1501B,
all the basic and advanced features and tells you how to use the slr digital cameras.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from Nikon service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the Used Nikon D5200 DSLR Camera (Body Only) 1501B. User manuals are also
available on the Nikon website under - Refurbished - SLR Digital Cameras.
