Simplifying the task of inputting audio and video into a standard PC, and avoiding the need for dedicated digitizing hardware in your PC, the Vaddio AV Bridge CONFERENCE HD Audio/Video Encoder handles HDMI, YPbPr, and even SD video signals. The encoder converts the signals to a video stream compatible with PCs that do not have specialized hardware or drivers. It features an internal web browser interface, allowing you to set up and control the unit over a network, or by using RS-232 over an RJ-45 connector.

Suitable for single-hall applications, the AV Bridge CONFERENCE converts NTSC/PAL signals up to 1080p 60 into MJPEG for USB streaming. It allows you to connect the video from almost any conference room setup to a PC or across a network. The unit can be used to retrofit existing conference rooms with newer infrastructure without upgrading the cameras or audio equipment. It includes rubber feet and rack mount ears, allowing you to use it on a desk top or in a rack.
If you own a Vaddio automated camera components and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Vaddio AV Bridge CONFERENCE HD Audio/Video Encoder 999-8215-001 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Vaddio AV Bridge CONFERENCE HD Audio/Video Encoder 999-8215-001:
Specifications
Supported Input Resolutions HDMI
1080p 60/59.94/50/30/25/24
720p 60/59.94/50
1080i 59.94/50

YPbPr
1080p: 60/59.94/50/30/25
720p: 60/59.94/50
1080i: 59.94/50

RGBHV
1280 x 720 60Hz (16:9)
1280 x 768 60Hz (15:9)m
1280 x 800 60Hz (16:10)
1360 x 768 60Hz (16:9)
1024 x 768 60Hz (4:3 centered in 16:9 frame)

DVI (On the HDMI connector using sRGB color space)
1080p: 60/59.94/50
720p: 60/59.94/50Hz frames/s
1080i: 59.94/50Hz
1440 x 900 60Hz
1360 x 768 60Hz
1280 x 800 60 Hz
1280 x 768 60Hz
1280 x 720 60Hz

EDID Supported Resolutions
1080p: 60/59.94/50
720p: 60/59.94/50H
1440 x 900 60Hz
1360 x 768 60Hz
1280 x 800 60 Hz

Composite (SD-Standard Definition)
NTSC
PAL
Video Encoding H.264 (IP)
MJPEG (USB)
Resolution IP: Up to 1080p 30
USB: 720p 30
Audio Encoding IP: AAC (variable bit rate)
USB: PCM
Video Input 1 x HDMI
1 x YPbPr/RGBHV
1 x Composite
Analog Audio Input
1 x XLR-F (nominal line level +4dBu), balanced 10k ohm
1 x RCA-F (nominal line level -10dBV), unbalanced 10k ohm

Output
1 x XLR-M, balanced 50 ohm
1 x RCA, unbalanced 10k ohm
USB 2.0 Interface
Connector Type-B Female, USB 2.0 Compliant
Supported Drivers: USB Video Class, (UVC), USB Audio Class (UAC)
Network Interface 1 x RJ-45 (10/100 Base-T)
IP Streaming RTSP
HLS
RS-232 1 x RJ-45
Power Supply Connector: 5.5 mm O.D. x 2.5 mm I.D> Coaxial
18 VDC
2.75 A
Power Consumption <50 W
Operating Temperature 32 to 104°F / 0 to 40°C
Dimensions (W x H x D) 18.9 x 1.7 x 7.0" / 48.0 x 4.3 x 17.8 cm
Weight 3.1 lb / 1.4 kg
The user manual for the Vaddio AV Bridge CONFERENCE HD Audio/Video Encoder 999-8215-001 can be downloaded in .pdf format if it did not come with your new automated camera components, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Vaddio users keep a unique electronic library for Vaddio automated camera componentss, where you can use our link to download the user manual for the Vaddio AV Bridge CONFERENCE HD Audio/Video Encoder 999-8215-001.

The user manual lists all of the functions of the Vaddio AV Bridge CONFERENCE HD Audio/Video Encoder 999-8215-001, all the basic and advanced features and tells you how to use the automated camera components. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Vaddio service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Vaddio AV Bridge CONFERENCE HD Audio/Video Encoder 999-8215-001. User manuals are also available on the Vaddio website under Professional Video - Camcorder & Camera Peripherals - Automated Camera Components.
