Designed to handle larger optical tube assemblies and heavy imaging rigs, Vixen's Sphinx SXD2 Equatorial Mount provides a precise and stable motorized mount for long observation sessions, or long-exposure astrophotography. Dual stepper motors provide smooth and virtually vibration-free tracking that run at up to 250pps. Its full-circle brass wheel gear allows the mount to track over extremely long periods with little tracking error.
If you own a Vixen Optics mounts and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Vixen Optics Sphinx SXD2 Equatorial Mount with Star Book 58705 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Vixen Optics Sphinx SXD2 Equatorial Mount with Star Book 58705:
Mount Type German Equatorial
Load Capacity 33 lb (15 kg)
Gears RA: 72mm diameter, 180-tooth full circle micro-movement gear, Brass wheel
Dec: 72mm diameter, 180-tooth full circle micro-movement gear, Brass wheel
Worm Wheel 9 mm diameter, Brass
Right Ascension Axis 35 mm in diameter, Carbon steel
Declination Axis 40 mm in diameter, Carbon steel
Motor 2 x Stepping (pulse) motors with 250 PPS
Bearings 9
GO-TO Capability Yes, with included Star Book Ten controller
Altitude / Azimuth Adjustment Alt: 0 to 70°
Az: ±7°
Polar Axis Scope Built-in 6 x 20 scope
Field of View: 8°
Bubble level
Illuminated reticle
Includes Tripod/Pier No
Counterweights 1 x 8.2 lb (3.7 kg)
1 x 4.2 lb (1.9 kg)
Power 12 VDC
Consumption: 0.45 to 2.2 A (with a 10 kg payload), 0.6 to 2.5 A (with a 15 kg payload)
Dimensions 13.5 x 14.2 x 5.0" (34.3 x 36.0 x 12.8 cm)
Weight 20.3 lb (9.2 kg), excluding counterweights
