User manual for the Weldex 5" Open-Frame Touch Screen Monitor WDL-5002TCM
The user manual for the Weldex 5" Open-Frame Touch Screen Monitor WDL-5002TCM provides
necessary instructions for the proper use of the product Surveillance - Surveillance Video - Surveillance Monitors.
The 5" Open-Frame Touch Screen Monitor from Weldex displays images with resolutions up to 960 x 234 pixels. Supporting 16.7M colors with 250 cd/m² brightness, the monitor depicts the finest details accurately and clearly. The touch screen interface with the on-screen display menu provides feature and video adjustments for quick changes to contrast, color, language, and video and input selection. It also features a D-Sub input for video signals.
|
If you own a Weldex surveillance monitors and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Weldex 5" Open-Frame Touch Screen Monitor WDL-5002TCM in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Weldex 5" Open-Frame Touch Screen Monitor WDL-5002TCM:
Touchscreen | Resistive 4-wire controller USB or serial interface RS-232 | Diagonal Screen Size | 5.0" (12.7 cm) | Resolution | 960 (W) x 234 (H) | Brightness | 400 cd/m2 | Contrast Ratio | 150:1 | Dot Pitch | 0.107 x 0.31 mm | Active Area | 102.72 x 74.53 mm | Viewing Angle (H x V) | Up: 15° / Down: 35° / Right:55° / Left:55° | Touch Screen | Resistive 4-wire Controller USB or Serial Interface RS-232 | Color System | NTSC / PAL | Video Input | 1 x Composite (RCA); 1 x VGA | Audio Input | 1 x Mono Audio (RCA) | Power Requirement | 12 to 32 VDC | Operating Temperature | -4 to 176°F (-20 to 80°C) | Dimensions (WxHxD) | 5.9 x 4.9 x 1.3" (14.9 x 12.4 x 3.3 cm) | Weight | 1.1 lb (0.5 kg) | |
