User manual Yamaha P2500S - Two Channel Power Amplifier P2500S

Operating instructions and pdf manual for use - Yamaha P2500S - Two Channel Power Amplifier P2500S User manual, User manual Yamaha P2500S - Two Channel Power Amplifier P2500S, Yamaha, P2500S, Two, Channel, Power, Amplifier, P2500S,


User manual for Yamaha P2500S - Two Channel Power Amplifier P2500S

Overall rating 5.0
Overall Rating: 5.0

100% of respondents would recommend this to a friend.
Yamaha P2500S - Two Channel Power Amplifier P2500S
  • Manufacturer: Yamaha
  • Basic description and contents of package
  • Product classification: Pro Audio - Live Sound - Power Amplifiers
  • Safety instructions
  • Startup and operation of the power amplifiers
  • Tips for setting up your Yamaha
  • Settings and expert assistance
  • Contact Yamaha service
  • Troubleshooting
  • Warranty information
  • Price: 420 USD
We recommend checking out our discussion threads on the Yamaha P2500S - Two Channel Power Amplifier P2500S, which address similar problems with connecting and setting up Power Amplifiers Yamaha.



User manual for the Yamaha P2500S - Two Channel Power Amplifier P2500S

The user manual for the Yamaha P2500S - Two Channel Power Amplifier P2500S provides necessary instructions for the proper use of the product Pro Audio - Live Sound - Power Amplifiers.

The Yamaha P2500S is a rack-mountable stereo power amplifier for sound reinforcement applications offering 250 watts per channel at 8 ohms and a moderate weight for its size. The P2500S has been optimized for use with Yamaha's Club Series speakers and is equipped with a YS engagement switch, which activates proprietary circuitry that matches the output of the amplifier to the capability of the speakers; that being said, speakers from all other manufacturers are supported as well and the YS circuitry is defeatable.

Another exclusive feature of the P2500S is the EEEngine energy conservation design, which obtains the same full output that conventional amplifier designs offer, but with half the power consumption. This attribute, in conjunction with a full complement of thermal and limiting overload protection, allows for cooler, quieter operation and improved frequency response with minimized distortion. The P2500S has XLR and 1/4" balanced inputs and Neutrik Speakon, binding post and 1/4" speaker outputs for connection to almost any sound system.

The rear panel offers several filtering options, the YS activation switch, and a mode switch - the amplifier supports stereo, bridged, and parallel operation. There is a comprehensive group of bright, color-coded LED activity indicators, and the front panel channel attenuator knobs are thoughtfully recessed and protectively covered. Yamaha has built a lot of value into the P2500S and made it available to budget-conscious schools, club date musicians, and event facilities at a very reasonable price.
If you own a Yamaha power amplifiers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Yamaha P2500S - Two Channel Power Amplifier P2500S in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Yamaha P2500S - Two Channel Power Amplifier P2500S:
Output Power Rating @ 1kHz, THD=1%
275W @ 8Ω Stereo (per channel)
390W @ 4Ω Stereo (per channel)
780W @ 8Ω Bridged-Mono

Rating @ 20Hz - 20kHz, THD=0.1%
250W @ 8Ω Stereo (per channel)
310W @ 4Ω Stereo (per channel)
620W @ 8Ω Bridged-Mono

Rating @ 1kHz, 20ms Nonclip
650W @ 2Ω Stereo (per channel)
1300W @ 4Ω Bridged-Mono
Damping Factor Greater than 200 (8 ohms, 1kHz)
Input Sensitivity +3dB (8 ohms, Max Attenuation)
Input Impedance 30 k ohms (Balanced)
15 k ohms (Unbalanced)
Gain 32.1dB
Frequency Response 20Hz - 50kHz (0dB, +0.5dB, -1dB @ 1 Watt, 8 ohms)
Signal-to-Noise Ratio 100dB
Total Harmonic Distortion (THD) Less than 0.1%, 20Hz - 20kHz, Half Power
Input Connections 2 x 3-pin XLR Female (Balanced)
2 x 1/4" (6.3mm) TRS Phone (Balanced)
Output Connectors 2 x Speakon
2 x 5-way Binding Post
2 x 1/4" (6.3mm) Phone
Controls Front Panel 1 x Push On/Off Power Switch
2 x 31-Position Attenuator Knobs
Controls (Rear) 1 x Stereo/Bridge/Parallel Mode Switch
2 x Subwoofer/Low Cut/Off Filter Switches
2 x 25Hz - 150Hz Frequency Control Switches
1 x Yamaha Speaker Processing On/Off Switch
Indicators 1 x Green Power On LED
1 x Red Protection LED
1 x Red Heatsink Temp Overheat LED
1 x Yellow YS Processor LED
2 x Green Signal LEDs
2 x Red Clip LEDs
Cooling Dual Variable-Speed Fans
Power Consumption Idle: 25W
1/8 (4 ohms): 320W
Maximum (4 ohms): 1600W
Power Requirements 120V 60Hz
Dimensions 19 x 3.5 x 18" (483 x 89 x 457 mm)
Weight 30.9 lbs (14 kg)
Specialties Proprietary EEEngine Operating Efficiency Design
Limiter Amp Protection Circuitry
YS Processing
Packaging Info
Package Weight 34.0 lb
Box Dimensions (LxWxH) 22.5 x 22.0 x 8.0"
The user manual for the Yamaha P2500S - Two Channel Power Amplifier P2500S can be downloaded in .pdf format if it did not come with your new power amplifiers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Yamaha users keep a unique electronic library for Yamaha power amplifierss, where you can use our link to download the user manual for the Yamaha P2500S - Two Channel Power Amplifier P2500S.

The user manual lists all of the functions of the Yamaha P2500S - Two Channel Power Amplifier P2500S, all the basic and advanced features and tells you how to use the power amplifiers. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Yamaha service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Yamaha P2500S - Two Channel Power Amplifier P2500S. User manuals are also available on the Yamaha website under Pro Audio - Live Sound - Power Amplifiers.
