User manual for the Yorkville Sound VGM14 Passive Compact Mixer with 10 Mono VGM14

The user manual for the Yorkville Sound VGM14 Passive Compact Mixer with 10 Mono VGM14 provides necessary instructions for the proper use of the product Pro Audio - Recording - Analog Recording Mixers.

The Yorkville Sound VGM14 Passive Compact Mixer with 10 Mono XLR & 1/4" Inputs and Global Phantom Power is designed for installed and live sound reinforcement applications such as in a club, bar, or music venue. The mixer unit features an all metal chassis, reinforced I/O connectors, 60mm faders, global +48V phantom power, sixteen 24-bit digital effects with TRS output and defeat footswitch jack, USB audio I/O, media I/O via RCA connectors, two high impedance instrument level inputs, a stereo 9-band graphic equalizer, XLR and TRS outputs, a separate sub/zone output, and a break switch to simultaneously mute all input channels.

Each input channel of the mixer features a balanced XLR microphone input, a 1/4" line input, a 1/4" insert, a switchable high-pass filter, gain control, 3-band EQ with mid-sweep control, monitor output control, auxiliary output control, EFX control, pan control, solo switch, mute switch, and a 60mm fader. The effect section includes sixteen presets including room reverb, hall reverb, plate reverb, gated reverb, fast echo, chorus, flanger, rotary speaker, harmonizer and more.

The stereo 9-band graphic EQ allows you to adjust the frequency response of your overall mix and a 12 VDC LED lamp BNC connector output allows you to connect an external lamp for viewing the device in low light venues. The mixer is supplied power via a standard IEC AC line cord, eliminating the need for a proprietary adapter or wall-wart.
If you own a Yorkville Sound analog recording mixers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Yorkville Sound VGM14 Passive Compact Mixer with 10 Mono VGM14 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Yorkville Sound VGM14 Passive Compact Mixer with 10 Mono VGM14:
Specifications
    Number of Channels 14
    Channel Inserts 10
    Equalization Mono: 3-band with mid sweep
    Stereo: 4-band
    Balance Control Channels: 11/12, 13/14
    Panning Range Channels: 1 to 10
    Overload Protection Yes
    Inputs XLR (balanced): 12
    1/4": 14
    RCA: 1 stereo pair
    Solo/Mute All channels
    High Pass Filter All channels
    Solo/Mute All channels with LED indicator light
    Clip All channels with LED indicator light
    Phantom Power +48V with LED indicator light
    Effects Engine 24-bit stereo / 16 effects with modify control
    Auxiliary Sends Yes
    Effects Sends Yes
    Effects Return Yes
    Return to Main: Yes
    Return to Monitor: Yes
    Foot Switch yes
    Record Output Yes (RCA and USB)
    Maximum Gain To Line Out-Mic Input (dB): 80 dB
    To Line Out-Line Input (dB): 65 dB
    Signal to Noise Ratio Greater than 100 dB
    Frequency Response 20 to 20,000 Hz
    Reference Input -118 dBV (at 150Ω)
    THD Less than 0.05%
    Crosstalk Less than -60 dB
    CMRR 55 dB / 65 dB
    Power Consumption 26 VAC (typical)
    Cooling Fan
    Transformer SMPS
    Chassis Steel
    Console Light Connector: 12 VDC (BNC)
    Dimension (DxWxH) 16.00 x 19.00 x 2.80" (40.60 x 48.30 x 7.10 cm)
    Weight 13 lb (5.9 kg)
    The user manual for the Yorkville Sound VGM14 Passive Compact Mixer with 10 Mono VGM14 can be downloaded in .pdf format if it did not come with your new analog recording mixers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Yorkville Sound users keep a unique electronic library for Yorkville Sound analog recording mixerss, where you can use our link to download the user manual for the Yorkville Sound VGM14 Passive Compact Mixer with 10 Mono VGM14.

    The user manual lists all of the functions of the Yorkville Sound VGM14 Passive Compact Mixer with 10 Mono VGM14, all the basic and advanced features and tells you how to use the analog recording mixers. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Yorkville Sound service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Yorkville Sound VGM14 Passive Compact Mixer with 10 Mono VGM14. User manuals are also available on the Yorkville Sound website under Pro Audio - Recording - Analog Recording Mixers.
