Designed specifically to address the needs of crossbow shooters, the 2-7x32 Terra XB75 Crossbow Scope from Zeiss features an XB75 reticle for ballistic compensation from 20 to 75 yards with 2.5 yard increments. Coupled with a special eyepiece zoom ring that has marks for velocity settings from 274 to 425 ft/s, the reticle will always provide correct yardages. The scope also features a weather-sealed housing to create a well-equipped optic for shooting in any weather. Zeiss' Terra Crossbow scope housing is a nitrogen-filled one-inch tube that is built to deliver fogproof performance. Inside the lightweight aluminum housing is a lens system that is multicoated with Zeiss MC anti-reflective coating to enhance the contrast and clarity of the transmitted image.

The Terra Crossbow scope is configured with an XB75 reticle in the second focal plane. The XB75 pattern has three medium-weight posts and a series of vertical marks that allow you to shoot at distances up to 75 yards in 2-1/2 yard increments. The scope is parallax-free from 100 to 30 yards.

Complementing the multicoated optics is a generous 3.55" eye relief and diopter correction that helps to provide the shooter with comfortable sighting. In addition to its build quality and optical performance, the 2-7x32 scope has low-profile, capped windage and elevation turrets that enable 1/4 MOA increments.
If you own a Zeiss riflescopes and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Zeiss 2-7x32 TERRA XB75 Crossbow Scope (XB75) 522724-9986-000 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Zeiss 2-7x32 TERRA XB75 Crossbow Scope (XB75) 522724-9986-000:
Specifications
    Magnification 2.3 - 7x
    Objective Lens Diameter 32 mm
    Main Tube Diameter 1"
    Reticle XB75
    2nd focal plane
    Field of View 46.5 - 13.5 ft (14.2 - 4.1 m) at 100 yd
    Angle of View 7.4 - 2.5°
    Eye Relief 3.55"
    Exit Pupil Diameter 12.2 - 4.6 mm
    Diopter Adjustment ±2.5
    Parallax Correction 30-100 yd
    Impact Point Correction 1/4 MOA
    Maximum Windage/Elevation Adjustment 62 MOA
    Operating temperature -13 to 122°F (-25 to 50°C)
    Watertight 13.3 ft (4 m)
    Length 11.5" (29 cm)
    Weight 13.4 oz (380 g)
    Packaging Info
    Package Weight 2.3 lb
    Box Dimensions (LxWxH) 14.5 x 3.8 x 3.8"
