User manual for the Zylight F8-200 Daylight LED Fresnel 26-01043
The user manual for the Zylight F8-200 Daylight LED Fresnel 26-01043 provides
necessary instructions for the proper use of the product Lighting & Studio - Continuous Lighting - LED Lights.
Embrace the variable beam angle of a Fresnel light while keeping a compact kit by using the F8-200 Daylight LED Fresnel from Zylight. It has a flat shape and an 8" lens that extends away from the body, but closes down for storage and transport. Inside is a 200W Quantum Dot LED with a CRI of 92 that gives this unit an output equivalent to that of a 400W HMI fixture. Also, it is balanced with a 5600K color temperature and has an adjustable beam angle from 16-70°. Also, the light can be dimmed from 0-100% via local controls, over DMX, or by using the ZyLink Wireless system.
The physical design is quite durable with an IP54-rated weather resistance and active cooling for reducing heat. It accepts power via a 4-pin XLR input and can accept an optional battery caddie for true portability. Along with this, it has a yoke mount for use on a light stand and comes with a universal AC power supply.
If you own a Zylight led lights and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Zylight F8-200 Daylight LED Fresnel 26-01043 in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Zylight F8-200 Daylight LED Fresnel 26-01043:
Specifications
Light Source
Quantum Dot LED
CRI
92
Color Temperature
5600K
Beam Angle
16-70°
Dimming
0-100%
Control
DMX512 Local ZyLink Wireless
Weather Resistance
IP54
Mount
Yoke with 5/8" spigot
Cooling
Active
Power Requirements
24-32 VDC via 4-pin XLR 2 x 14.4 V batteries via optional caddie
Power Consumption
200 W (10 A at 24 VDC)
Dimensions
15.0 x 12.6 x 4.6" / 38 x 32 x 12 cm
Weight
10.25 lb / 4.7 kg
