User manual for the Atlas Sound AA120 120 Watt 6-Channel Mixer Amplifier AA120
The user manual for the Atlas Sound AA120 120 Watt 6-Channel Mixer Amplifier AA120 provides
necessary instructions for the proper use of the product Pro Audio - Installation Sound - Mixer/Amplifiers.
The AA120 from Atlas Sound is a 120 watt, 6-channel mixer amplifier designed for commercial audio applications. A key feature of the unit is a unique bridge in/out, which allows combining of multiple amplifiers without the need for external relays. The AA120 also features extensive muting and output options, along with assignable VCA control.
|
If you own a Atlas Sound mixer/amplifiers and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Atlas Sound AA120 120 Watt 6-Channel Mixer Amplifier AA120 in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Atlas Sound AA120 120 Watt 6-Channel Mixer Amplifier AA120:
| Output Power | 120W | | Damping Factor | Not Specified by Manufacturer | | Input Sensitivity | Inputs 1-5: 316 mV (-10dBV) Line/Mic
Input 6: 300 mV/100 mV (-10dBV/-20dBV) Switchable | | Input Impedance | 10 k ohm | | Gain | Not Specified by Manufacturer | | Frequency Response | 50Hz - 20kHz | | Signal-to-Noise Ratio | Mic: > 55dB
Line: > 55dB
Telephone: 75 dB | | Total Harmonic Distortion (THD) | Less than 1.0% | | Input Connections | 5 x Mic/Line Balanced Phoenix
2 x RCA (1 Pair) | | Output Connectors | 5 x RCA
2 x Phoenix
Rear-Panel Barrier Strip | | Controls Front Panel | Power On/Off, Individual Channel Volume Controls, Master Volume Control, Individual Bass and Treble Controls | | Controls (Rear) | Input Dipswitches and Trim Knobs | | Indicators | Front-Panel Power, Peak, and Signal LEDs | | Cooling | Not Specified by Manufacturer | | Power Consumption | 300W | | Dimensions (WxHxD) | 16.6 x 4.25 x 14.1" (422 x 108 x 358 mm) | | Weight | 26.4 lbs (12 kg) (Shipping Weight) | | Specialties | VCA Remote Connector, AC Outlet for Adding Extra Device | | Package Weight | 30.0 lb | | Box Dimensions (LxWxH) | 20.0 x 17.0 x 7.5" | |
The user manual for the Atlas Sound AA120 120 Watt 6-Channel Mixer Amplifier AA120 can be downloaded in .pdf
format if it did not come with your new mixer/amplifiers, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other Atlas Sound users keep a unique electronic library
for Atlas Sound mixer/amplifierss,
where you can use our link to download the user manual for the Atlas Sound AA120 120 Watt 6-Channel Mixer Amplifier AA120.
The user manual lists all of the functions of the Atlas Sound AA120 120 Watt 6-Channel Mixer Amplifier AA120,
all the basic and advanced features and tells you how to use the mixer/amplifiers.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from Atlas Sound service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the Atlas Sound AA120 120 Watt 6-Channel Mixer Amplifier AA120. User manuals are also
available on the Atlas Sound website under Pro Audio - Installation Sound - Mixer/Amplifiers.
Question and answer discussion forum concerning user instructions and resolving problems with the Atlas Sound AA120 120 Watt 6-Channel Mixer Amplifier AA120
Post new comment to Atlas Sound AA120 120 Watt 6-Channel Mixer Amplifier AA120
Subject: AA120 power LED not glowing  | | Date: 22.05.2025 00:35:21 | Author: Stephen Roth | I have some Atlas AA120's that work but the power LED does not glow. There is only 1.5VDC on the LED and if I give it 3V it lights nicely.
There are two limiting resistors in parallel feeding the LED and about 23V feeding them. They (together) measure 19.5kOhms. I'm wondering if I replace them with 10K will the voltage go up to 3V? | | Reply |
| Subject: Service manual | | Date: 10.10.2016 00:20:02 | Author: Paul | | I need a service manual for the AA120 Atlas mixer/amplifier in order to repair my unit | | Reply |
| Subject: Wiring Schematic | | Date: 10.10.2016 00:14:31 | Author: Paul | | How can I get a wiring schematic to trouble shoot the AA120 Atlas mixer/amplifier | | Reply |
