User manual Fargo DTC1250e Dual-Sided ID Card Printer 50100

Operating instructions and pdf manual for use - Fargo DTC1250e Dual-Sided ID Card Printer 50100 User manual, User manual Fargo DTC1250e Dual-Sided ID Card Printer 50100, Fargo, DTC1250e, Dual-Sided, ID, Card, Printer, 50100, Video


User manual for Fargo DTC1250e Dual-Sided ID Card Printer 50100

Fargo  DTC1250e Dual-Sided ID Card Printer 50100
  • Manufacturer: Fargo
  • Basic description and contents of package
  • Product classification: Computers & Solutions - Printers & Accessories - ID Card Printers
  • Safety instructions
  • Startup and operation of the id card printers
  • Tips for setting up your Fargo
  • Settings and expert assistance
  • Contact Fargo service
  • Troubleshooting
  • Warranty information
Fargo  DTC1250e Dual-Sided ID Card Printer 50100 Fargo  DTC1250e Dual-Sided ID Card Printer 50100 Fargo  DTC1250e Dual-Sided ID Card Printer 50100 Fargo  DTC1250e Dual-Sided ID Card Printer 50100 Fargo  DTC1250e Dual-Sided ID Card Printer 50100 Fargo  DTC1250e Dual-Sided ID Card Printer 50100
Click to enlarge image

We recommend checking out our discussion threads on the Fargo DTC1250e Dual-Sided ID Card Printer 50100, which address similar problems with connecting and setting up ID Card Printers Fargo.



User manual for the Fargo DTC1250e Dual-Sided ID Card Printer 50100

The user manual for the Fargo DTC1250e Dual-Sided ID Card Printer 50100 provides necessary instructions for the proper use of the product Computers & Solutions - Printers & Accessories - ID Card Printers.

The Fargo DTC1250e Dual-Sided ID Card Printer is a well-featured printer that utilizes dye sublimation and resin thermal transfer processes to quickly create 300 dpi resolution prints. This dual-sided printer works with CR-80 and CR-79 adhesive back card sizes and can print edge-to-edge. The printer is also fast with the ability to print black & white at a rate of 6 seconds per card or full color with two black resin panels at 24 seconds per card. The printer can also hold 100 cards in the input hopper and 100 cards in the output hopper.

The embedded Swift ID badging application allows you to design custom badges on the spot and the FARGO Workbench maintenance software has monitoring features that will make maintaining your printer easier. The DTC1250e also has a SmartScreen graphical display for setup and operation and is ENERGY STAR qualified. It has a USB 2.0 interface for connecting to a computer.
If you own a Fargo id card printers and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Fargo DTC1250e Dual-Sided ID Card Printer 50100 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Fargo DTC1250e Dual-Sided ID Card Printer 50100:
Printing Method
Printing Technology Dye sublimation / resin thermal transfer
Maximum Resolution 300 dpi (11.8 dots/mm) continuous tone
Colors Supported 16.7 million / 256 shades per pixel
Ribbon Options EZ and ECO
Full-color with resin black and overlay panel, YMCKO (250 prints)
Resin black, standard (1000 prints)
ECO Only
Full-color half-panel with resin black and overlay pane, YMCKO (350 prints)
EZ Only
Full-color with two resin black panels and overlay panel, YMCKOK (200 prints)
Resin black and overlay panel, KO (500 prints)
Resin black, premium (1000 prints)
Dye-sublimation black and overlay panel, BO (500 prints)
Resin green, blue, red, white, silver, gold (1000 prints)
Silver and gold metallic (500 prints)

Rewrite technology, no ribbon is required
Card cleaning roller integrated into ribbon cartridge that is automatically replaced with each ribbon change
Performance
Print Speed K: 6 sec/card
KO: 8 sec/card
YMCKO: 16 sec/card
TMCKOK: 24 sec/card
Card Sizes CR-80: 3.375 x 2.125" (85.6 x 54.0 mm)
CR-79 Adhesive Back: 3.313 x 2.063" (84.1 x 52.4 mm)
Print Area CR-80 Edge-to-Edge: 3.36 x 2.11" (85.3 x 53.7 mm)
CR-79: 3.3 x 2.04" (83.8 x 51.8 mm)
Media Thickness 9-40 mil (0.229-1.016 mm)
Double/Single-Sided Dual
Card Type PVC of polyester card with polished PVC finish
Monochrome resign required for 100% polyester cards
Optical memory cards with PVC finish
Rewrite
Paper Capacity Input: 100 cards with 30 mil (0.762 mm) thickness
Output: 100 cards with 30 mil (0.762 mm) thickness
Encoding None
Connectivity
Computer Interface USB 2.0
Memory 32 MB RAM
System & Software Requirements Windows XP, Vista (32/64-bit), Server 2003 & 2008, 7, 8 (32/64-bit)
Mac OS X 10.5-10.8
Linux
Physical
Front Panel Buttons Color changing status buttons
Certifications Safety: UL 60950-2, CSA C22.2 (60950-07), and CE
EMC: FCC Class A, CE (EN 55022 Class A, EN 55024), CCC, BSMI, KC
Environmental: ENERGY STAR qualified
Operating Temperature 65 to 80°F (18 to 27°C)
Humidity 20-80%, non-condensing
Power Requirements 100-240 VAC, 50-60 Hz, 1.6 A max
Dimensions 9.8 x 18.7 x 9.2" (249 x 475 x 234 mm)
Weight 10 lb (4.5 kg)
Packaging Info
Package Weight 16.4 lb
Box Dimensions (LxWxH) 21.6 x 15.3 x 11.9"
The user manual for the Fargo DTC1250e Dual-Sided ID Card Printer 50100 can be downloaded in .pdf format if it did not come with your new id card printers, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Fargo users keep a unique electronic library for Fargo id card printerss, where you can use our link to download the user manual for the Fargo DTC1250e Dual-Sided ID Card Printer 50100.

The user manual lists all of the functions of the Fargo DTC1250e Dual-Sided ID Card Printer 50100, all the basic and advanced features and tells you how to use the id card printers. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Fargo service.

If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Fargo DTC1250e Dual-Sided ID Card Printer 50100. User manuals are also available on the Fargo website under Computers & Solutions - Printers & Accessories - ID Card Printers.
