User manual for the Fujifilm X-E2 Mirrorless Digital Camera with 18-55mm 16405018

The user manual for the Fujifilm X-E2 Mirrorless Digital Camera with 18-55mm 16405018 provides necessary instructions for the proper use of the product Photography - Digital Cameras - Mirrorless System Cameras.

The black Fujifilm X-E2 Mirrorless Digital Camera features a 16.3 megapixel, APS-C, X-Trans CMOS II sensor and an EXR Processor II to provide high quality imagery and exceptional camera performance. The combination of the sensor and processor enables a native sensitivity range from ISO 200-6400, which is further expandable to ISO 100-25600. Fujifilm's proprietary X-Trans sensor uses a unique randomized pixel array in order to avoid the use of a resolution-reducing optical low-pass filter, therefore providing images with the utmost sharpness and clarity. This imaging system is benefitted by the Intelligent Hybrid AF system, which uses both contrast- and phase-detection methods to acquire focus quickly and accurately. Enhanced manual focusing capabilities are also a result of these technologies; Digital Split Image and Focus Highlight Peaking are two methods for quickly and precisely determining focus using intelligent focusing aids for improved control and optimized efficiency. The EXR Processor II also delivers fast performance speeds to all aspects of the camera, ranging from quick startup and shutter lag times to a fast 7 fps continuous shooting rate.

For image monitoring, review, and menu navigation, both a 2,360k-dot OLED electronic viewfinder and a 3.0" 1,040k-dot LCD screen are available. The body design extends this versatility through the implementation of manual, physical control dials on the top plate of the camera as well as four different customizable buttons and a Q Menu button for expedited access to some of the most useful settings. This control scheme further enables an intuitive built-in Wi-Fi system for direct sharing of imagery to an Android or iOS mobile device for instant sharing online.

Full HD 1080p movie recording in multiple frame rates is possible and a 2.5mm microphone input permits the use of an optional external microphone for improved audio quality with recordings. Full-time continuous focusing is supported while taking video, also, as well as the use of Film Simulation modes. Film Simulation modes make use of Fujifilm's history of producing both negative and slide films and allow you to apply those films' characteristics to your digital imagery to better suit your intended look.

Included with the X-E2 is the XF 18-55mm f/2.8-4 R LM OIS lens; a standard zoom lens providing a 35mm-equivalent focal length range of 27-84mm, covering wide-angle to portrait-length perspectives. This lens integrates optical image stabilization to minimize the appearance of camera shake to benefit working with longer shutter speeds or greater focal lengths and a linear motor-drive AF system provides fast, smooth focusing capabilities.
If you own a Fujifilm mirrorless system cameras and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Fujifilm X-E2 Mirrorless Digital Camera with 18-55mm 16405018 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for Fujifilm X-E2 Mirrorless Digital Camera with 18-55mm 16405018Download user manual for Fujifilm X-E2 Mirrorless Digital Camera with 18-55mm 16405018
(PDF file, 3.12 MB)
Additional parameters of the Fujifilm X-E2 Mirrorless Digital Camera with 18-55mm 16405018:
Specifications
    Imaging
    Lens Mount Fujifilm X Mount
    Camera Format APS-C (1.5x Crop Factor)
    Pixels Actual: 16.7 Megapixel
    Effective: 16.3 Megapixel
    Max Resolution 4896 x 3264
    Sensor Type / Size CMOS, 23.6 x 15.6 mm
    File Formats Still Images: JPEG, RAW
    Movies: H.264, MOV
    Audio: Linear PCM (Stereo)
    Memory Card Type SD
    SDHC
    SDXC
    AV Recording
    Video Recording Yes
    Resolution 1920 x 1080: 60 fps, 30 fps
    1280 x 720: 60 fps, 30 fps
    Aspect Ratio 16:9
    Video Clip Length Up to 27 Min
    Audio Recording Built-in Mic: With Video, Stereo
    Optional External Mic: With Video
    Focus Control
    Focus Type Auto & Manual
    Focus Mode Single-servo AF (S), Continuous-servo AF (C), Manual Focus (M)
    Autofocus Points Contrast Detection: 49
    Viewfinder/Display
    Viewfinder Type Electronic
    Viewfinder Size 0.5"
    Viewfinder Pixel Count 2,360,000
    Viewfinder Eye Point 23.00 mm
    Viewfinder Coverage 100%
    Diopter Adjustment - 4 to +2 m
    Display Screen 3" Front Screen   LCD (1,040,000)
    Screen Coverage 100%
    Exposure Control
    ISO Sensitivity Auto, 200-6400 (Extended Mode: 100-25600)
    Shutter Type: Electronic & Mechanical
    Speed: 1/4 - 1/4000  in  Program Mode
    Type: Electronic & Mechanical
    Speed: 30 - 1/4000
    Type: Electronic & Mechanical
    Speed: 60 - 0  in  Bulb Mode
    Type: Electronic & Mechanical
    Speed: 30 - 1/2  in  Time Mode
    Remote Control RR-90 (Optional)
    Metering Method Average metering, Multi-zone metering, Spot metering
    Exposure Modes Modes: Aperture Priority, Manual, Programmed Auto, Shutter Priority
    Compensation: -3 EV to +3 EV (in 1/3 EV steps)
    White Balance Modes Automatic Scene Recognition, Color Temperature, Custom, Fine, Fluorescent (Cool White), Fluorescent (Daylight), Fluorescent (Warm White), Incandescent, Shade, Underwater
    Burst Rate Up to 7 fps at 16.3 MP for up to 28 frames
    Up to 3 fps at 16.3 MP
    Flash
    Flash Modes Auto
    Auto/Red-eye Reduction
    Commander
    Commander/Red-eye Reduction
    Forced On
    Forced On/Red-eye Reduction
    Rear Curtain Sync/Red-eye Reduction
    Rear Sync
    Slow Sync
    Slow Sync/Red-eye Reduction
    Built-in Flash Yes
    Guide No. 22.97' (7 m) ISO200
    Max Sync Speed 1 / 180 seconds
    Dedicated Flash System TTL
    External Flash Connection Hot Shoe, Wireless
    Performance
    Start-up Time 0.5 seconds
    Continuous Shooting Up to 7 fps
    Self Timer 10 seconds, 2 seconds
    Connectivity 2.5mm Sub-mini (3-Ring), HDMI C (Mini), USB 2.0
    Wi-Fi Capable Yes
    Software System Requirements Windows: XP, Vista, 7, 8
    Mac: OS X 10.6 or later
    Power
    Battery 1x NP-W126 Rechargeable Lithium-ion Battery Pack, 7.2 VDC, 1260 mAh
    Operating/Storage Temperature Operating
    32 to 104°F (0 to 40°C)
    Humidity: 10 - 80%
    Physical
    Dimensions (WxHxD) 5.1 x 2.9 x 1.5" / 129.0 x 74.9 x 37.2 mm minimum depth: 1.2" / 30.9 mm
    Weight 12.35 oz / 350 g with battery and memory card
    Kit Lens
    Focal Length 18 - 55mm
    Comparable 35mm Focal Length: 27 - 84 mm
    Aperture Maximum: f/2.8 - 4
    Minimum: f/22
    Angle of View 79.1° - 28.4°
    Minimum Focus Distance 11.81" (30 cm)
    Magnification 0.08 - 0.15x
    Elements/Groups 14/10
    Diaphragm Blades 7
    Autofocus Yes
    Image Stabilization Yes
    Filter Thread Front:58 mm
    Dimensions (DxL) Approx. 2.56 x 2.77" (65 x 70.4 mm)
    Weight 10.93 oz (310 g)
    Packaging Info
    Package Weight 3.4 lb
    Box Dimensions (LxWxH) 8.4 x 7.5 x 5.6"
    The user manual for the Fujifilm X-E2 Mirrorless Digital Camera with 18-55mm 16405018 can be downloaded in .pdf format if it did not come with your new mirrorless system cameras, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Fujifilm users keep a unique electronic library for Fujifilm mirrorless system camerass, where you can use our link to download the user manual for the Fujifilm X-E2 Mirrorless Digital Camera with 18-55mm 16405018.

    The user manual lists all of the functions of the Fujifilm X-E2 Mirrorless Digital Camera with 18-55mm 16405018, all the basic and advanced features and tells you how to use the mirrorless system cameras. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Fujifilm service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Fujifilm X-E2 Mirrorless Digital Camera with 18-55mm 16405018. User manuals are also available on the Fujifilm website under Photography - Digital Cameras - Mirrorless System Cameras.
