User manual for the NZXT Phantom Full-Sized Tower PHAN-002GR
The user manual for the NZXT Phantom Full-Sized Tower PHAN-002GR provides
necessary instructions for the proper use of the product Computers & Solutions - Computer Components - Desktop Computer Cases.
The black with green stripes Phantom Full-Sized Tower from NZXT is engineered to offer enhanced control and expandability. It supports E-ATX, ATX, Micro-ATX motherboard form factors. Phantom's cooling capabilities include seven fan cooling option with dual 200mm, single side 230/200mm (fitment with NZXT's FN-200), triple 120mm, front 140mm fans. It includes dual radiator support, quad water-cooling cutouts, and an integrated fan controller with up to five 20W channels. In addition, this tower case is also equipped with seven expansion slots, a mic input, headphone output, eSATA port, five-channel fan controller, and two USB 2.0 ports for peripheral connectivity.
If you own a NZXT desktop computer cases and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the NZXT Phantom Full-Sized Tower PHAN-002GR in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the NZXT Phantom Full-Sized Tower PHAN-002GR:
Specifications
Motherboard Support
E-ATX, ATX, Micro-ATX
Drive Bays
5 x External 5.25" drive bays 7 x Internal 3.5"/2.5" slots Screw-less rail design
Cooling System
Front: 1 x 140 mm Rear: 1 x 120 mm (included) Side: 2 x 120 mm, 1 x 200/230 mm (2 x 120 mm included) Top: 2 x 200 mm (1 x LED 200 mm included)
Filters
Top dual 200 mm filters (included) Side (included)
Radiator Support
Top: 2 x 120 mm
Clearance
CPU Cooler: 170 mm VGA Card: 350 mm Cable Management: 23 mm
Expansion Slots
7
External Electronics
1 x 3.5mm mic in 1 x 3.5 headphone out 2 x USB 2.0 1 x eSATA 5-Channel fan controller
