User manual for the Pelco ES4036-5N ESPRIT SE Standard Positioning System ES40365N
The user manual for the Pelco ES4036-5N ESPRIT SE Standard Positioning System ES40365N provides
necessary instructions for the proper use of the product Surveillance - Surveillance Video - Wired Analog & HD Cameras.
The Pelco ES4036-5N ESPRIT SE Standard Positioning System features a receiver, a pan/tilt unit, an enclosure, and an IOP (Integrated Optics Package) in a single easy-to-install system. The positioning system includes a high resolution color / B&W camera (540 TVL) with an infrared-cut filter, 432X zoom (36X optical, 12X digital), electronic image stabilization, and wide dynamic range.
If you own a Pelco wired analog & hd cameras and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Pelco ES4036-5N ESPRIT SE Standard Positioning System ES40365N in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Pelco ES4036-5N ESPRIT SE Standard Positioning System ES40365N:
24, 120, or 230 VAC, 50/60 Hz Switch selectable for 120/230 VAC inputs
Input Voltage Range
±10%
Power Consumption
Maximum 70 VA per system
Heater
Thermostatically controlled
Defroster
Thermostatically controlled
Connections
2 power source connections made at mount location with wire splices and 1 ground wire splice 1 BNC receptacle and 4 wire splices at mount location for RS-422 Pelco D and Pelco P protocols 2 wire splices for open collector auxiliary output
AUX 2
Open collector output with 2 sec activation; connected relay must require no more than 32 VDC and 40 mA to energize relay coil; wire length between ESPRIT SE System and relay must be less than 100.0' (30.4 m)
-50.0 to 122°F (-45.5 to 50°C) for sustained system operation or 140°F (60°C) absolute maximum; within 2 hours after power-up, the entire unit can de-ice and be operational from a temperature of -13°F (-25°C)
Operating Environment
Will remain operational in 145 kmph (90 mph) wind conditions Withstands a wind velocity of up to 209 kmph (130 mph)
Auxiliary Output
1
Dimensions (H x W x D)
17.5 x 7.7 x 13.3" (44.4 x 19.5 x 33.7 cm)
Weight
20.00 lb (9.07 kg) with included pedestal adapter plate
The user manual for the Pelco ES4036-5N ESPRIT SE Standard Positioning System ES40365N can be downloaded in .pdf
format if it did not come with your new wired analog & hd cameras, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other Pelco users keep a unique electronic library
for Pelco wired analog & hd camerass,
where you can use our link to download the user manual for the Pelco ES4036-5N ESPRIT SE Standard Positioning System ES40365N.
The user manual lists all of the functions of the Pelco ES4036-5N ESPRIT SE Standard Positioning System ES40365N,
all the basic and advanced features and tells you how to use the wired analog & hd cameras.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from Pelco service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the Pelco ES4036-5N ESPRIT SE Standard Positioning System ES40365N. User manuals are also
available on the Pelco website under Surveillance - Surveillance Video - Wired Analog & HD Cameras.
