User manual for the Pentax 645Z Medium Format DSLR Comprehensive Starter Kit KB16599

The user manual for the Pentax 645Z Medium Format DSLR Comprehensive Starter Kit KB16599 provides necessary instructions for the proper use of the product Photography - Digital Cameras - Medium Format Cameras.

Comprising everything needed to enter the world of digital medium format photography, the 645Z Comprehensive Starter Kit from Pentax pairs the high-resolution camera body with a trio of lenses and a suite of accessories to provide you with a well-rounded tool-set from the beginning.

The 645Z is a unique DSLR featuring the large 51.4MP 43.8 x 32.8mm CMOS sensor, which, along with the Prime III image processor, is capable of producing exceptionally clear 14-bit imagery with notable sharpness and a broad dynamic range. The sensor's design also omits the conventional anti-aliasing filter for increased sharpness and resolution. The processor and sensor combination also avails a top continuous shooting rate of 3 fps, a sensitivity range of ISO 100-204,800, and the ability to record full HD 1080 video at 60i, 30p, or 24p frame rates. A 27-point SAFOX 11 AF system, which includes 25 cross-type sensors and three dedicated low-light sensors, is capable of producing fast, accurate focusing with a light sensitivity range from -3 to +18 EV. Complementing the imaging capabilities, the 645Z is also characterized by its durable magnesium alloy body construction that incorporates 76 protective seals to guard against water, fog, snow, sand, and dust. A 3.2" 1.037m-dot tilting LCD is available for live view monitoring, image playback, and menu navigation, and dual SD card slots allow you to make in-camera file backups or partition your DNG/PEF and JPEG files while shooting.

Included with the camera body are three lenses: a wide zoom, standard prime, and a telephoto macro prime. The smc PENTAX-D FA 645 55mm f/2.8 AL [IF] SDM AW provides a slightly wider-than-normal 35mm-equivalent focal length of 43.5mm and uses aspherical elements to reduce aberrations and distortions for increased clarity and sharpness. A bit wider, the HD PENTAX-DA645 28-45mm f/4.5 ED AW SR offers a versatile 35mm-equivalent focal length range of 22-35.5mm and features a constant f/4.5 maximum aperture for consistent performance throughout the zoom range. Two extra-low dispersion elements and two aspherical elements benefit image quality and sharpness and an integrated Shake Reduction image stabilization system compensates for up to 3.5 stops of camera shake. Finally, the third lens in the kit is the HD PENTAX-D FA 645 Macro 90mm f/2.8 ED AW SR, which offers a 71mm equivalent focal length and provides a 1:2 reproduction ratio with a 1.4' minimum focusing distance for working with close-up subjects. Its optical design features two extra-low dispersion elements and one glass-molded aspherical element to control aberrations and distortions, while a floating lens mechanism maintains accurate, consistent performance at varying focus distances. This lens, too, incorporates Shake Reduction image stabilization to benefit handheld shooting. All three of these lenses also feature Supersonic Direct-drive Motors for fast, smooth autofocus performance and are also weather-sealed to match the durable design of the 645Z body.

Complementing the imaging components, this kit also includes the Advantage Platinum program, which encompasses a three-year extended warranty for the camera body and each of the lenses; free access to loaner equipment, in the instance your camera or lenses need to be sent in for repair; and one comprehensive cleaning and inspection of your camera and lenses. Additionally, also included in the kit is a pair of 32GB SDHC memory cards, an extra D-LI90 lithium-ion battery, and a wheeled hard case with custom-cut foam interior for protecting and traveling with the kit.
If you own a Pentax medium format cameras and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Pentax 645Z Medium Format DSLR Comprehensive Starter Kit KB16599 in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for Pentax 645Z Medium Format DSLR Comprehensive Starter Kit KB16599Download user manual for Pentax 645Z Medium Format DSLR Comprehensive Starter Kit KB16599
(PDF file, 16.68 MB)
Additional parameters of the Pentax 645Z Medium Format DSLR Comprehensive Starter Kit KB16599:
Specifications
  • 645Z Medium Format DSLR Camera (Body Only)
    Camera Type TTL autofocus, auto-exposure medium format digital SLR camera
    Sensor 43.8 x 32.8 mm CMOS
    Color Depth JPEG: 8 bits/channel
    RAW: 14 bits/channel
    Effective Pixels 51.4MP
    Total Pixels 52.99MP
    File Formats Stills: RAW (PEF/DNG), TIFF, JPEG (Exif 2.30), DCF2.0 compliant
    Video: MPEG-4 AVC/H.264 (MOV) *Motion JPEG (AVI) for Interval Movie Record
    Resolution JPEG: L (51M: 8256 x 6192), M (36M: 6912 x 5184), S (21M: 5376 x 4032), XS (3M: 1920 x 1440)
    RAW: L (51M: 8256 x 6192)
    TIFF: L (51M: 8256 x 6192)
    Image Quality JPEG: ★★★ (Best), ★★ (Better), ★ (Good), RAW + JPEG simultaneous recording available
    RAW: PEF, DNG
    Video Resolution Full HD: (1920x1080, 60i/50i/30p/25p/24p)
    HD: (1280x720, 60p/50p/30p/25p/24p)
    Video Recording Time Up to 25 minutes
    Dust Removal Image sensor cleaning using ultrasonic vibrations "DR II" with the Dust Alert function
    Lens Mount PENTAX 645AF2 mount with AF coupler, lens information contacts, and power contacts (stainless steel)
    Lenses PENTAX 645AF2, 645AF and 645A mount lenses PENTAX 67 medium format lenses useable with adapter
    SDM function: Yes
    Image Stabilization Lens-shift type (when using SR system lens)
    Metering System TTL open aperture metering using 86K pixel RGB sensor
    Metering Range EV -1 to 21 (ISO 100 at 55mm f/2.8)
    Metering Modes Multi-segment metering, Center-weighted metering, Spot metering
    Exposure Compensation ±5 EV (1/3 EV steps or 1/2 EV steps)
    AE Lock Button type (timer-control: two times the meter operating time set in Custom Setting), Continuous as long as the shutter release button is depressed halfway
    Exposure Bracketing 2, 3, or 5 frames, Available with Continuous, Self-timer, or Remote Control
    ISO Sensitivity Auto, 100 to 204,800 (EV steps can be set to 1EV, 1/2EV, or 1/3EV)
    White Balance Auto, Multi Auto, Daylight, Shade, Cloudy, Fluorescent Light (D: Daylight Color, N: Daylight White, W: Cool White, L: Warm White), Tungsten, Flash, CTE
    Manual mode(s): Manual (up to 3 settings can be saved), Color Temperature (up to 3 settings can be saved), Copying the white balance settings of a captured image possible.
    Shutter Type Electronically controlled, vertical-run, focal plane shutter
    Shutter Speeds Auto: 1/4000 to 30 sec.
    Manual: 1/4000 to 30 sec. (1/3 EV steps or 1/2 EV steps)
    Bulb
    Exposure Modes Program, Sensitivity Priority, Shutter Priority, Aperture Priority, Shutter & Aperture Priority, Manual, Bulb, Flash X-sync Speed, USER1, USER2, USER3
    Drive Mode Single Frame, Continuous (H, L), Self-timer (12 sec., 2sec.), Remote Control (immediately, 3 sec., continuous), Multi-exposure (available with Continuous, Self-timer or Remote Control), Interval Shooting, Interval Composite
    Self Timer Yes - 12 seconds, 2 seconds
    Remote Control Yes - infrared (0 seconds, 3 seconds, continuous), cable switch
    Burst Rate 3 fps, JPEG ( L: ★★★ at Continuous H): up to 30 frames, RAW: up to 10 frames, TIFF: up to 12 frames
    Focus System SAFOX II TTL phase-matching autofocus with 27 AF points (25 cross type focus points in the center)
    AF Modes Single AF (AF.S), Continuous AF (AF.C), Manual, Focus operation customizable
    Focus Area Spot, Select, Expanded Area AF (S, M, L), Zone Select, Auto (27 AF Points)
    Brightness EV -3 to 18 (ISO 100, at normal temperature)
    Viewfinder Type Kepler-telescopic, trapezoid prism finder
    Viewfinder Coverage Approximately 98%
    Viewfinder Magnification 0.62x (55mm f/2.8 at infinity); 0.85x (75mm f/2.8 at infinity)
    Focusing Screen Standard: Interchangeable Natural-Bright-Matte focusing screen
    Diopter Adjustment -3.5 m to + 2.0 m-1
    Depth of Field Preview Optical (diaphragm stop-down), Digital
    Eye-Relief Length Approximately 21 mm (from view window)
    Approximately 24.1 mm (from center of lens)
    LCD Monitor 3.2" 1037k-Dot Tiltable TFT Color LCD
    Electronic Level Displayed in viewfinder and LCD panel (horizontal direction only); displayed on LCD monitor (horizontal direction and vertical direction)
    Live View TTL using CMOS image sensor
    Live View Field of View 100%
    Live View Autofocus Contrast detection AF (Face Detection, Tracking, Multiple AF Points, Select, Spot
    Focus Peaking: On/Off
    External Flash Hotshoe (P-TTL), high speed sync and wireless with PENTAX dedicated flash, X-Sync Socket
    Flash Modes Flash On, Flash On+Red-eye Reduction, Slow-speed Sync, Slow-speed Sync+Red-eye, P-TTL, Trailing Curtain Sync, contrast-control-sync, high-speed sync, wireless sync (available with a dedicated external flash)
    Flash Exposure Compensation -2 to +1 EV (1/2 steps)
    Flash Synch Speeds 1/125 sec
    Storage Media SD, SDHC*, SDXC* memory card, Eye-Fi card, FLUCARD (*UHS-I compatible)
    Dual Card Slot: Sequential save, Save to Both Dual save, Separate RAW/JPG, Copying images between slots possible
    Interfaces Connection Ports: USB 3.0 (micro B), external power supply terminal, cable switch terminal, X-sync socket, HDMI output terminal (Type D), stereo microphone input terminal (USB Connection: MSC/PTP)
    Video out: HD (via HDMI), NTSC, PAL
    Computer System Requirements Windows: Windows 8.1 (32 bit/64 bit) / Windows 8 (32 bit/64 bit) / Windows 7 (32 bit/64 bit) / Windows Vista (32 bit/64 bit), Intel Core 2 Quad or higher, 4GB or more
    Mac: Mac OS X 10.9 /10.8 / 10.7 / 10.6, Intel Core 2 Quad or higher, 4GB or more
    Power Supply Rechargeable Li-Ion battery D-LI90
    AC adapter available: AC Adapter Kit K-AC132 (Optional)
    Material of Construction Magnesium alloy shell over aluminum chassis
    Weather Resistant Yes - 76 special seals
    Operating Temperature 14 to 104°F / -10 to 40°C
    Dimensions 6.1 x 4.6 x 4.8" / 15.5 x 11.7 x 12.2 cm (excluding protrusions)
    Weight 54.7 oz / 1.55 kg (including battery and memory card)
    Packaging Info
    Box Dimensions (LxWxH) 10.0 x 9.291 x 8.583"
  • Pentax-D FA 645 55mm f/2.8 AL[IF] SDM AW Lens
    Focal Length 55 mm
    Aperture Maximum: f/2.8
    Minimum: f/22
    Camera Mount Pentax 645
    Angle of View @ Infinity 65°
    Minimum Focus Distance 1.64' (49.99 cm)
    Diaphragm Blades 9
    Elements/Groups 9/7
    Magnification 0.17x
    DOF Scale Yes
    Distance Scale Yes
    PC Outlet No
    Autofocus Yes
    Tripod Collar No
    Filter Thread Front: 67 mm
    Weight 14.67 oz (416 g)
    Dimensions Approx. 2.69 x 3.20" (68.2 x 81.3 mm)
    Packaging Info
    Box Dimensions (LxWxH) 5.7 x 4.6 x 4.5"
  • HD PENTAX-DA645 28-45mm f/4.5 ED AW SR Lens
    Focal Length 28 - 45 mm
    Aperture Maximum: f/4.5
    Minimum: f/32
    Camera Mount Pentax 645
    Angle of View @ Infinity 89° - 63°
    Minimum Focus Distance 1.31' (.4 m)
    Diaphragm Blades 9
    Elements/Groups 17/12
    Magnification 0.21x
    DOF Scale No
    Distance Scale Yes
    Autofocus Yes
    Tripod Collar No
    Movements None
    Filter Thread Front: 82 mm
    Weight 3.24 lb (1.47 kg)
    Dimensions Approx. 3.90 x 5.96" (99 x 151.5 mm)
    Packaging Info
    Box Dimensions (LxWxH) 8.898 x 7.165 x 5.669"
  • 90mm f/2.8 D FA 645 Macro ED AW SR Lens
    Focal Length 90 mm

    Equivalent to 71mm in 35mm format
    Aperture Maximum: f/2.8
    Minimum: f/22
    Camera Mount Pentax 645
    Angle of View @ Infinity 34°
    42.5°

    34° with Pentax 645D, 42.5° with 645 film
    Minimum Focus Distance 1.36' (41.45 cm)
    Diaphragm Blades 9
    Elements/Groups 11/9
    Magnification 0.5x
    DOF Scale Yes
    Distance Scale Yes
    Autofocus Yes
    Filter Thread Front: 67 mm
    Weight 36.69 oz (1040 g)
    Dimensions Approx. 3.56 x 4.39" (90.5 x 111.6 mm)
    Packaging Info
    Box Dimensions (LxWxH) 8.8 x 7.1 x 5.5"
  • D-LI90(E) Lithium-Ion Battery (7.2V, 1860mAh)
    Chemistry Lithium-ion
    Capacity 1860 mAh
    Output Voltage 7.2 V
    Power Consumption 14 Wh
    Temperature Range Up to 140°F (60deg;C)
    Certifications UL, CE
    Dimensions Not specified by manufacturer
    Weight Not specified by manufacturer
    Packaging Info
    Box Dimensions (LxWxH) 2.3 x 1.7 x 1.5"
The user manual for the Pentax 645Z Medium Format DSLR Comprehensive Starter Kit KB16599 can be downloaded in .pdf format if it did not come with your new medium format cameras, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Pentax users keep a unique electronic library for Pentax medium format camerass, where you can use our link to download the user manual for the Pentax 645Z Medium Format DSLR Comprehensive Starter Kit KB16599.

The user manual lists all of the functions of the Pentax 645Z Medium Format DSLR Comprehensive Starter Kit KB16599, all the basic and advanced features and tells you how to use the medium format cameras. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Pentax service.
