User manual for the Samsung CY-TD40LDAH Infrared Touch Overlay CY-TD40LDAH
The user manual for the Samsung CY-TD40LDAH Infrared Touch Overlay CY-TD40LDAH provides
necessary instructions for the proper use of the product A/V Presentation - Whiteboards, Easels & Displays - Whiteboard & Wall Display Accessories.
The CY-TD40LDAH Infrared Touch Overlay from Samsung adds touch capability to compatible 40" Samsung Signage eliminating the costly need of purchasing new displays. The Touch Overlay places a layer over the panel surface to allow the user's finger to slide along the surface easily experiencing up to 10 simultaneous points of touch. The added layer also provides protection against the external environment. If desired, a SBB or PIM can be added, but is not needed. The overlay is compatible with Samsung D-Series displays and Windows, Mac, and Linux operating systems. Installation hardware is included for a quick and simple installation.
If you own a Samsung whiteboard & wall display accessories and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Samsung CY-TD40LDAH Infrared Touch Overlay CY-TD40LDAH in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Samsung CY-TD40LDAH Infrared Touch Overlay CY-TD40LDAH:
Specifications
Diagonal Screen Size
40.0" / 101.6 cm
Glass Thickness
0.1" / 2.8 mm
Glass Film
Front: AG Rear: PET
Glass Reflection Rate
≤10%
Glass Haze
≤15%
Frame Material
Aluminum extrusion
Bezel Width
1.2" / 30.0 mm
Touch Technology
IR
Number of Simultaneous Touch
2 drawing, 10 touch
Response Time
1-point: 12 ms
Dimensions
37.2 x 22.0 x 1.2" / 945.1 x 558.5 x 30.9 mm
Weight
13.4 lb / 6.1 kg
Compatibility
Samsung D-Series 40 displays
OS Supported
Windows 8/7/XP, Win7 Embedded, WinXP Embedded, Mac OSX, Linux
