User manual for the Sony a7S Alpha Mirrorless Digital Camera ILCE7S/B

The user manual for the Sony a7S Alpha Mirrorless Digital Camera ILCE7S/B provides necessary instructions for the proper use of the product Photography - Digital Cameras - Mirrorless System Cameras.

The Sony Alpha a7S Mirrorless Digital Camera features a full-frame 12.2MP Exmor CMOS sensor and BIONZ X image processor to enable notable video and still image quality with an expansive dynamic range, low noise, and extended sensitivity to ISO 409600. At the sensor level, this full-frame sensor features a unique on-chip gapless lens design, which incorporates small lenses between neighboring pixels in order to increase light-gathering efficiency and promote greater image quality across the entirety of the sensor plane. The sensor and processor combination also avails a wealth of speed throughout the camera system, including a top continuous shooting rate of 5 fps, support for 4K video recording, and a fast 25-point contrast-detection AF system with sensitivity to -4 EV.

Beyond its still image performance, the a7S is also quite adept in regard to recording video. It is able to output uncompressed 4:2:2 UHD 4K video to an optional external recorder over HDMI, as well as record full HD 1080p video in the high-quality XAVC S format at 50 Mbps in multiple frame rates. Extending the video recording capabilities is support for S-Log2 gamma, which helps to expand the effective dynamic range during recording, as well as picture profile options, time code, and zebra marker display aids. Sound can be recorded in the AAC/Linear PCM format via the internal stereo microphone, with a built-in headphone jack for on-board monitoring, or via an external microphone.

Rounding out the a7S's imaging capabilities, both a 3.0" 921.6k-dot tilting LCD monitor and 2.36 million-dot OLED electronic viewfinder are available for image monitoring and review. Built-in Wi-Fi connectivity, with support for NFC, is available, too, for instant sharing of imagery from the camera as well as remote camera control from a linked mobile device.
If you own a Sony mirrorless system cameras and have a user manual in electronic form, you can upload it to this website using the link on the right side of the screen.

You can upload and download the manual for the Sony a7S Alpha Mirrorless Digital Camera ILCE7S/B in the following formats:
  • *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
User manual for Sony a7S Alpha Mirrorless Digital Camera ILCE7S/BDownload user manual for Sony a7S Alpha Mirrorless Digital Camera ILCE7S/B
(PDF file, 9.07 MB)
Additional parameters of the Sony a7S Alpha Mirrorless Digital Camera ILCE7S/B:
Specifications
    Imaging
    Lens Mount Sony E-Mount
    Camera Format Full-Frame
    Pixels Actual: 12.4 Megapixel
    Effective: 12.2 Megapixel
    Max Resolution 12 MP: 4240 x 2832
    Aspect Ratio 3:2, 4:3
    Sensor Type / Size CMOS, 35.8 x 23.9 mm
    File Formats Still Images: JPEG, RAW
    Movies: MP4, MPEG-4 AVC/H.264
    Audio: AAC LC, AC3, Dolby Digital 2ch, Linear PCM
    Bit Depth 14-bit
    Dust Reduction System Yes
    Memory Card Type SD
    SDHC
    SDXC
    Memory Stick PRO Duo (High Speed)
    Memory Stick PRO HG-Duo
    Memory Stick XC-HG Duo
    AV Recording
    Video Recording Yes, NTSC
    Resolution 1920 x 1080: 60 fps, 30 fps, 24 fps
    1280 x 720: 120 fps
    1440 x 1080: 30 fps
    640 x 480: 30 fps
    Video Format High Definition
    1920 x 1080p / 60 fps (50 Mbps)
    1920 x 1080p / 30 fps (50 Mbps)
    1920 x 1080p / 24 fps (50 Mbps)
    High Definition
    1280 x 720p / 120 fps (50 Mbps) (50 Mbps)
    High Definition
    AVCHD
    1920 x 1080p / 60 fps (28 Mbps)
    1920 x 1080i / 60 fps (24 Mbps)
    1920 x 1080i / 60 fps (17 Mbps)
    High Definition
    AVCHD
    1920 x 1080p / 24 fps (24 Mbps)
    1920 x 1080p / 24 fps (17 Mbps)
    High Definition
    MP4
    1440 x 1080p / 30 fps (12 Mbps)
    Standard Definition
    MP4
    640 x 480p / 30 fps (3 Mbps)
    Aspect Ratio 4:3, 16:9
    Video Clip Length Not Specified By Manufacturer
    Audio Recording Built-in Mic: With Video, Stereo
    Optional External Mic: With Video
    Focus Control
    Focus Type Auto & Manual
    Focus Mode Continuous-servo AF (C), Direct Manual Focus (DMF), Manual Focus (M), Single-servo AF (S)
    Autofocus Points Contrast Detection:25
    Viewfinder/Display
    Viewfinder Type Electronic
    Viewfinder Size 0.5"
    Viewfinder Pixel Count 2,359,296
    Viewfinder Eye Point 27.00 mm
    Viewfinder Coverage 100%
    Viewfinder Magnification Approx. 0.71x
    Diopter Adjustment - 4 to +3 m
    Display Screen 3" Rear Screen Tilting  LCD (921,600)
    Screen Coverage 100%
    Exposure Control
    ISO Sensitivity Auto, 100-102400 (Extended Mode: Auto, 50-409600)
    Shutter Type: Electronic & Mechanical
    Speed: 30 - 1/8000 second,  Bulb Mode
    Type: Electronic & Mechanical
    Speed: 1/4 - 1/8000 second in  Movie Mode
    Remote Control RM-VPR1 (Optional)
    Metering Method Center-weighted average metering, Multi-zone metering, Spot metering
    Exposure Modes Modes: Aperture Priority, Auto, Intelligent Auto, Manual, Movie, Programmed Auto, Scene Selection, Shutter Priority, Superior Auto, Sweep Panorama
    Metering Range: EV 3.0 - EV 20.0
    Compensation: -5 EV to +5 EV (in 1/3 or 1/2 EV steps)
    White Balance Modes Auto, Cloudy, Color Temperature, Color Temperature Filter, Custom, Daylight, Flash, Fluorescent (Cool White), Fluorescent (Day White), Fluorescent (Daylight), Fluorescent (Warm White), Incandescent, Shade, Underwater
    Continuous Shooting Up to 5 fps at 12.2 MPfor up to 200 frames
    Up to 2.5 fps at 12.2 MPfor up to 200 frames
    Flash
    Flash Modes Auto
    Fill-in
    Hi-Speed Sync
    Off
    Rear Sync
    Red-eye Reduction
    Slow Sync
    Wireless
    Built-in Flash No
    Max Sync Speed 1 / 250 seconds
    Flash Compensation -3 EV to +3 EV (in 1/3 or 1/2 EV steps)
    External Flash Connection Hot Shoe, Proprietary
    Performance
    Self Timer 10 seconds, 2 seconds
    Connectivity 1/8" Headphone, 1/8" Microphone, DC Input, HDMI D (Micro), Micro-USB
    Wi-Fi Capable Yes
    Software System Requirements Windows: Vista (SP2), 7 (SP1), 8
    Mac: OS X 10.6 or later
    Power
    Battery 1x NP-FW50 Rechargeable Lithium-ion Battery Pack, 7.2 VDC, 1080 mAh
    AC Power Adapter AC-PW20 (Optional)
    Operating/Storage Temperature Operating
    32 to 104°F (0 to 40°C)
    Physical
    Dimensions (WxHxD) 5.0 x 3.7 x 1.9" / 126.9 x 94.4 x 48.2 mm
    Weight 1.08 lb / 489 g with battery and memory card
    Packaging Info
    Package Weight 2.5 lb
    Box Dimensions (LxWxH) 8.976 x 6.299 x 5.984"
    Sony a7S Demo
    The user manual for the Sony a7S Alpha Mirrorless Digital Camera ILCE7S/B can be downloaded in .pdf format if it did not come with your new mirrorless system cameras, although the seller is required to supply one. It is also quite common that customers throw out the user manual with the box, or put the CD away somewhere and then can’t find it. That’s why we and other Sony users keep a unique electronic library for Sony mirrorless system camerass, where you can use our link to download the user manual for the Sony a7S Alpha Mirrorless Digital Camera ILCE7S/B.

    The user manual lists all of the functions of the Sony a7S Alpha Mirrorless Digital Camera ILCE7S/B, all the basic and advanced features and tells you how to use the mirrorless system cameras. The manual also provides troubleshooting for common problems. Even greater detail is provided by the service manual, which is not typically shipped with the product, but which can often be downloaded from Sony service.

    If you want to help expand our database, you can upload a link to this website to download a user manual or service manual, ideally in .pdf format. These pages are created by you – users of the Sony a7S Alpha Mirrorless Digital Camera ILCE7S/B. User manuals are also available on the Sony website under Photography - Digital Cameras - Mirrorless System Cameras.
