The ICP-6530 24-Button Control Panel from Sony is designed for the MVS-6530 switcher. It features 3 M/E rows, 24 cross-point colored buttons, OLED mnemonic displays for optimal visibility, and an intuitive menu operation (menu display sold separately).
If you own a Sony switcher accessories and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Sony ICP-6530 24-Button Control Panel for MVS-6530 ICP6530 in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Sony ICP-6530 24-Button Control Panel for MVS-6530 ICP6530:
Specifications
Compatibility
MVS-6530 switcher
Connectors
RJ-45, 1000BaseT USB type A, Device 1 to 4 25-pin DVI-D output
Operating Temperature
41 to 104°F (5 to 40°C)
Operating Humidity
10 to 90%
Storage Temperature
-4 to 140°F (-20 to 60°C)
Power Requirements
100 - 240 VAC, 10%, 50/60 Hz
Current Consumption
Max 1.1 A
Inrush Current
46 A peak, 11 A rms (240 VAC)
Dimensions
45.4 x 15.6 x 7.1" (115.4 x 39.6 x 18.0 cm)
With screws
Weight
44.1 lb (20 kg)
