User manual for Yamaha R-N500 Network Receiver R-N500BL
- Manufacturer: Yamaha
- Basic description and contents of package
- Product classification: TVs & Entertainment - Receivers & Amplifiers - Receivers
- Safety instructions
- Startup and operation of the receivers
- Tips for setting up your Yamaha
- Settings and expert assistance
- Contact Yamaha service
- Troubleshooting
- Warranty information
- Price: 400 USD
|
We recommend checking out our discussion threads on the Yamaha R-N500 Network Receiver R-N500BL,
which address similar problems with connecting and setting up Receivers Yamaha.
|
User manual for the Yamaha R-N500 Network Receiver R-N500BL
The user manual for the Yamaha R-N500 Network Receiver R-N500BL provides
necessary instructions for the proper use of the product TVs & Entertainment - Receivers & Amplifiers - Receivers.
The Yamaha R-N500 Network Receiver features discrete amp configuration that supports 2-channels of stereo sound powered at up to 80W RMS per channel. There's also an unpowered subwoofer pre-out. The system supports network connectivity and provides AirPlay streaming as well. It works with Yamaha's free NP Controller app and supports sound enhancing ToP-ART technology.
|
If you own a Yamaha receivers and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Yamaha R-N500 Network Receiver R-N500BL in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Yamaha R-N500 Network Receiver R-N500BL:
| Channels | 2.1 (two powered channels with one subwoofer pre-out) | | Power Output | Minimum RMS Output Power (8 ohms, 20 Hz - 20 kHz, 0.04% THD): 80 W + 80 W
Maximum Power (4 ohms, 1 kHz, 0.7% THD, for Europe): 105 W + 105 W
Maximum Power (8 ohms, 1 kHz, 10% THD): 115 W + 115 W | | Total Harmonic Distortion (THD) | 8 ohms: 105 W
6 ohms: 125 W
4 ohms: 150 W
2 ohms: 178 W | | Frequency Response | 0 ± 0.5 dB / 0 ± 1.0 dB | | Total Harmonic Distortion (THD) | 0.015% (40 W, 8 ohms, CD to Sp out, 20 Hz - 20 kHz) | | Signal to Noise Ratio | CD: 100 dB (CD Direct on, 200 mV)
FM: 71 dB (mono)
FM: 69 dB (stereo) | | Inputs | USB port x 1
L/R RCA phono jack x 1
Digital optical jacks x 2
Digital coaxial jacks x 2
L/R RCA line jacks x 3
L/R RCA CD jack x 1
Ethernet jack x 1
FM antenna jack x 1
AM antenna jack x 1
Remote input x 1 | | Outputs | L/R RCA line outputs x 2
Subwoofer pre-out x 1
Headphone jack x 1
DC out x 1 (for optional accessories)
Remote output x 1 | | Sensitivity | FM 50dB Quieting Sensitivity (IHF, 1 kHz, 100% Mod., Mono): 3 µV (20.8 dBf) | | Technology Supported | ToP-ART Technology | | Network Features | DLNA: Version 1.5
File Formats: MP3, WMA, MPEG4, AAC, WAV, FLAC
AirPlay: Yes | | Standby Power Consumption | 0.1 W | | Dimensions (WxHxD) | 17.1 x 6 x 15.25" (435 x 152 x 387 mm) | | Weight | 21.6 lb (9.8 kg) | | Package Weight | 26.0 lb | | Box Dimensions (LxWxH) | 21.3 x 17.5 x 6.0" | |
The user manual for the Yamaha R-N500 Network Receiver R-N500BL can be downloaded in .pdf
format if it did not come with your new receivers, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other Yamaha users keep a unique electronic library
for Yamaha receiverss,
where you can use our link to download the user manual for the Yamaha R-N500 Network Receiver R-N500BL.
The user manual lists all of the functions of the Yamaha R-N500 Network Receiver R-N500BL,
all the basic and advanced features and tells you how to use the receivers.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from Yamaha service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the Yamaha R-N500 Network Receiver R-N500BL. User manuals are also
available on the Yamaha website under TVs & Entertainment - Receivers & Amplifiers - Receivers.
Question and answer discussion forum concerning user instructions and resolving problems with the Yamaha R-N500 Network Receiver R-N500BL
Post new comment to Yamaha R-N500 Network Receiver R-N500BL
| Subject: Pandora account set up | | Date: 01.01.2018 00:41:24 | Author: Marcus | | The display isn't long enough for my email address. I tried finishing up on the next address box so my email is split in 2 windows. I can't sign in and I can't delete the address figures I have already entered. What do I do? | | Reply |
