User manual for Yamaha R-S500 Natural Sound Stereo Receiver R-S500BL
Overall Rating: 4.5
90% of respondents would recommend this to a friend.
- Manufacturer: Yamaha
- Basic description and contents of package
- Product classification: TVs & Entertainment - Receivers & Amplifiers - Receivers
- Safety instructions
- Startup and operation of the receivers
- Tips for setting up your Yamaha
- Settings and expert assistance
- Contact Yamaha service
- Troubleshooting
- Warranty information
- Price: 350 USD
|
We recommend checking out our discussion threads on the Yamaha R-S500 Natural Sound Stereo Receiver R-S500BL,
which address similar problems with connecting and setting up Receivers Yamaha.
|
User manual for the Yamaha R-S500 Natural Sound Stereo Receiver R-S500BL
The user manual for the Yamaha R-S500 Natural Sound Stereo Receiver R-S500BL provides
necessary instructions for the proper use of the product TVs & Entertainment - Receivers & Amplifiers - Receivers.
With its continued excellence in sound reproduction, Yamaha has once again created a versatile stereo receiver for the music lover in you. The R-S500 Natural Sound Stereo Receiver offers superb functionality and dual-room capability that will be hard to match at this price point. Yamaha's features include continuously variable loudness control, Pure Direct along with Yamaha iPod dock connection, Sirius Radio Ready, 40-station AM/FM and Zone 2 control gives an assurance of total music enjoyment. Most of the receiver's audio processing is handled automatically, with little intervention on your part. However, it is so advanced; its discrete output reproduces music with unmatched sonic clarity and dynamic power.
In a nutshell, the R-S700 is a 2 x 75W stereo receiver capable of delivering breathtaking stereo sound. It features a ton of input jacks, a subwoofer out, individual treble, bass, and balance controls, Remote Interactive (RI) port, A/B speaker switching, banana plug speaker posts, and an AM/FM tuner. Because of the high efficiency of its design, this powerful receiver produces exceptional sound quality, and clarity in every audible detail.
|
If you own a Yamaha receivers and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Yamaha R-S500 Natural Sound Stereo Receiver R-S500BL in the following formats:
- *.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
|
Additional parameters of the Yamaha R-S500 Natural Sound Stereo Receiver R-S500BL:
| Surround RMS Power | 75W x 2 @ 8 ohms, 20Hz to 20kHz, 0.04% THD | | No. of Channels | 2 | | Impedance | 8, 6, 4, 2 ohms (105/125/150/178W) | | Maximum Output Power | 105W | | Power Bandwidth | 0.06% THD, 37.5W, 8 ohms->10Hz to 50kHz | | Damping Factor | 1kHz, 8 ohms->150 or more | | Maximum Output Power | 1kHz, 10%, 8 ohms-> 115W | | Input Sensitivity | Phono: 35mV/47 kohms
CD: 200mV/47 kohms | | Max Input Signal | Phono: (1kHz, 0.003% THD) 60mV or more CD: (1kHz, 0.5% THD) 2.2V or more | | Output Level | CD, (Input, 1kHZ, 200mV)
REC: 200mV/1.0 kohms
CD, (Input, 1kHz, 200mV, 8 ohms)
Phones: 410mV, 470 ohms | | Freq. Response (Rec/Repro) | CD, (10Hz to 100kHz) 0+/-1.0 db | | Equalization | Phono: 0+/-0.5 db | | THD | CD, etc. to Speakers
(20Hz to 20kHz, 50W, 8 ohms)->0.015% or less | | Signal to Noise Ratio | CD, (200mV) 100 db or more | | Residual Noise | 30 | | Channel Selection | CD, (5.1 kohms input shortened, 1/10kHz)->65/50 db or more | | Tone Control | BASS
Boost/Cut (50Hz) +/- 10 db
Turnover Frequency->350Hz
TREBLE
Boost/Cut (20KHz) +/- 10 db
Turnover Frequency->3.5kHz
Continuous Loudness Control
Attenuation (1kHz) -30 db
Gain tracking error (0-99 db)-> 0.5 db or less | | AM/FM Tuner | FM: 87.5 to 107.9 MHz
AM: 530 to 1710 kHz
40-Station Preset Tuning
Sirius Satellite Radio Ready | | Other Ports | Subwoofer Out
Pre-Out / Main-In Coupler
Zone 2 Output
IR Ports In x 1/ Out x 1
+12V Trigger Output
FM Antenna x 1
AM Antenna x 1
Dock Jack x 1
CD Jack x 1
Phono x 1
Tape Jack x 1
GND Terminal x 1
Sirius Tuner x 1 | | Power Requirements | AC 120V, 60Hz | | Power Consumption | 190W | | Power Consumption (idle) | 0.5W or less | | Maximum Power Draw | 380W | | Dimensions (WxHxD) | 17.1 x 6 x 15.3" (435 x 151 x 387mm) | | Weight | 22.5 lb. (10.2kg) | | Package Weight | 25.0 lb | | Box Dimensions (LxWxH) | 21.5 x 17.5 x 9.0" | |
The user manual for the Yamaha R-S500 Natural Sound Stereo Receiver R-S500BL can be downloaded in .pdf
format if it did not come with your new receivers, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other Yamaha users keep a unique electronic library
for Yamaha receiverss,
where you can use our link to download the user manual for the Yamaha R-S500 Natural Sound Stereo Receiver R-S500BL.
The user manual lists all of the functions of the Yamaha R-S500 Natural Sound Stereo Receiver R-S500BL,
all the basic and advanced features and tells you how to use the receivers.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from Yamaha service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the Yamaha R-S500 Natural Sound Stereo Receiver R-S500BL. User manuals are also
available on the Yamaha website under TVs & Entertainment - Receivers & Amplifiers - Receivers.
