User manual for the Zeiss Victory Diavari 2.5-10x50 T* Riflescope 52 17 30 9908
The user manual for the Zeiss Victory Diavari 2.5-10x50 T* Riflescope 52 17 30 9908 provides
necessary instructions for the proper use of the product Optics - Riflescopes & Sights - Riflescopes.
Where garden-variety 3-9x40 scopes come up short, the Victory Diavari 2.5-10x50 T* from Zeiss goes the extra mile - right up until the last bit of daylight. The combination of a broader magnification range with a notable 50mm objective offers a wide field of view, brilliant twilight performance, and enough power to reach out across greater distances.
If you own a Zeiss riflescopes and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Zeiss Victory Diavari 2.5-10x50 T* Riflescope 52 17 30 9908 in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Zeiss Victory Diavari 2.5-10x50 T* Riflescope 52 17 30 9908:
Specifications
Magnification
2.5-10x
Objective Lens Diameter
50 mm
Main-Tube Diameter
30 mm
Reticle
#8 - FFP
Field of View
2.5x: 8.3° - 43.5' @ 100 yd / 14.4 m @ 100 m 10x: 2.3° - 12' @ 100 yd / 3.9 m @ 100 m
Parallax Correction
Factory-set: 100 m / 110 yd
Eye Relief
2.5x: 3.54" / 9.0 cm 10x: 3.54" / 9.0 cm
Exit Pupil Diameter
2.5x: 15 mm 10x: 5.0 mm
Filter Size
Proprietary thread
Impact Point Correction
1/3 MOA / 1 cm @ 100 m
Maximum Windage/Elevation Adjustment
Windage: 44 MOA Elevation: 44 MOA
Weatherproofing
Water & fogproof
Dimensions
Length: 12.5" / 31.8 cm
Weight
17.5 oz / 495 g
The user manual for the Zeiss Victory Diavari 2.5-10x50 T* Riflescope 52 17 30 9908 can be downloaded in .pdf
format if it did not come with your new riflescopes, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other Zeiss users keep a unique electronic library
for Zeiss riflescopess,
where you can use our link to download the user manual for the Zeiss Victory Diavari 2.5-10x50 T* Riflescope 52 17 30 9908.
The user manual lists all of the functions of the Zeiss Victory Diavari 2.5-10x50 T* Riflescope 52 17 30 9908,
all the basic and advanced features and tells you how to use the riflescopes.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from Zeiss service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the Zeiss Victory Diavari 2.5-10x50 T* Riflescope 52 17 30 9908. User manuals are also
available on the Zeiss website under Optics - Riflescopes & Sights - Riflescopes.
